User instructions

Lock setup

Lock setup can be performed through a Dallas key properly programmed or through a direct
PC link. In both cases, lock must be in pre-setup mode (press 1 to open it).

Setup with Dallas key

Power up the keypad. Press and hold
Insert the setup Dallas key in the reader and connect the reader with
the keypad by means of the jack connector. LCD shows:
Check time and date. Press
Then, press again to confirm. LCD shows:
If the operation is successfully performed, LCD shows:

Setup with PC

Power up the keypad. Press and hold
Enter the manager code and press
Press until LCD shows:
Press , LCD shows:
Start the programming on the Setup software or press
If the operation is successfully performed, LCD shows the firmware
version and few seconds later the keypad switches OFF. Pease refer to
the user manual IU_DigiTech_setup_XX for further information.

Test mode

This function allows to check the correct system operation.
Power up the keypad. Press and old
Enter the sequence of buttons shown on the LCD.
Any working button produces a short beep.
A damaged button produces a long beep. LCD shows:
10 of 16
. LCD shows:
to confirm or to update the values.
. LCD shows:
. LCD shows:
. LCD shows:
DigiTech
SYSTEM SETUP
08:00 FRI
27/01/2019
CONFIGURAZIONE IN
CORSO
OPERATION DONE
TIME AND DATE
01-XXXXXX
TIME AND DATE
SETTINGS
PC LINK
PC LINK
to exit.
TEST MODE
1234567890 ➔
TEST MODE
1234567890 ➔
WRONG/FAULTY
IU_ DigiTech_04
10%
...
KEY
