For Windows 2000: From the desktop click the Start button,
point to Settings and then Network and Dial-up Connections.
Then right-click (NOT left-click) Local Area Connection, select
Properties, highlight your NIC card's TCP/IP entry (it should
start with TCP/IP and have the characters 10/100, NIC, or Ether
in it – and not have the words AOL, Dial-up, or Adapter). Click
Properties to display the Windows TCP/IP Properties dialog
box.
For Windows 98 and Me: From the desktop click the Start
button, then point to Settings and then Control Panel. Double-
click the Network icon to display the Network configuration
screen. Highlight your NIC card's TCP/IP entry (it should start
with TCP/IP and have the characters 10/100, NIC, or Ether in it
– and not have the words AOL, Dial-up, or Adapter). Click
Properties to display the Windows TCP/IP Properties dialog
box.
3 3 3 3
Windows Users Only: Enter the IP Settings.
For Windows 2000 and XP:
Click the Use the following IP address and Use the following
DNS server addresses buttons so that a black dot appears. Then
enter the settings for IP address, Subnet mask, Default
gateway, and Preferred DNS server. Most users can copy the
information exactly as it is shown in the chart below. However, if
you chose an IP address in Step 1 other than 10.2.2.16, enter
the number that you chose instead of 10.2.2.16. When done, click
continue with Step 6.
OK and
IP address
Subnet mask
Default gateway (V3's LAN IP address)
Preferred DNS server
For Windows 98 and Me:
Click Specify an IP Address and enter the settings for IP
Address and Subnet Mask shown below, unless you chose an
IP address in Step 1 other than 10.2.2.16, in which case you
should enter the number that you chose instead of 10.2.2.16.
46
10.2.2.16
255.255.255.0
10.2.2.2
10.2.2.2
