Zoom Gateway/Router V3 User Manual page 34

5 5 5 5
Fill out these fields:
IP Address
Subnet Mask
Default Gateway
or Router
Then select Continue.
6 6 6 6
Fill out these fields:
Primary DNS
Secondary DNS
Then select Continue.
7 7 7 7
Select Test Settings. A connection test runs. You will then see
the message, "The test for connecting to your ISP was
successful! Please save your network setting." If you are
unsuccessful, re-check the information you entered in Steps 5
and 6.
Then select Continue.
8 8 8 8
Now enter a Network Setting Name (anything you choose)
and then select Save. Your Service Provider setup is now
complete. Follow the prompts for online registration.
9 9 9 9
Now, using the computer connected to the V3, go to the V3's
Advanced Setup page and click the DMZ button. Then select
Enable from the DMZ dropdown list, and enter the static IP
address 10.2.2.50 in the DMZ Host IP field. Click Save
Changes, then Write Settings to Flash and Reboot, and
then Confirm to complete the process.
Important:
Outside game players need to know the V3's WAN IP address.
To find this address, click the System Status icon at the top of any
Zoom Configuration Manager page and scroll down to the
WAN Status section.
34
10.2.2.50
255.255.255.0
10.2.2.2
10.2.2.2
10.2.2.2
Zoom V3 User's Guide
