Product Description

3.1 General Description
EN
This device is an extraction unit for vacuuming-up dust generated by dental CAM equipment�
It can be manually operated or controlled by the CAM device�
The extraction unit is equipped with a bi-directional interface, which transfers status data to the CAM
device and records control commands from the CAM device�
The suction performance is fixed and cannot be altered.
3.2 Components and Functional Elements
1 SILENT compactCAM
2 Key-pad
3 Dust drawer
4 Fine filter
5 Mains cable
6 Suction hose
7 Exhaust air filter / exhaust air outlet
2
3
1
4
5
8 Suction port
9 On / off switch
10 Power supply
11 Device protection switch
12 CAM interface
13 Service flap
13
9 10
8
7
- 6 -
11
6
Fig. 1
