Interface cable Type E:
Extractor
RJ 45 pin
Pin 8
Pin 7
For use if the CAM system only has a floating contact between pin 8 and 9.
Interface cable Type F:
Extractor
RJ 45 pin
Pin 8
Pin 7
For use if the CAM system only has voltage for the
control of the extraction unit�
Interface cable Type G:
Extractor
RJ 45 pin
Pin 8
Pin 6
Pin 4
Pin 2
Pin 7
Pin 5
Pin 3
Pin 1

10 Warranty

The suction motor has a guarantee of 3 years, with a maximum of duration of 1000 operating
hours (motor running time).
Provided the unit is properly used, Renfert warrants all components for 3 years�
Warranty claims may only be made upon presentation of the original sales receipt from the authorized
dealer�
Parts which are subject to natural wear and tear (wear parts) and consumables are excluded from the
guarantee� These parts are marked in the spare part list�
The warranty is voided in the case of improper use; failure to observe the operating, cleaning, mainte-
nance and connection instructions; in case of independent repairs or repairs by unauthorized personnel;
if spare parts from other manufacturers are employed, or in case of unusual influences or influences not
in compliance with the utilization instructions�
Warranty service shall not extend the original warranty�
CAM device
9 Pin D-Sub
Pin 9
Pin 8
Power supply
24 V
GND
CAM device
Lumberg SV60
(with screw closure)
Pin 1 (+)
Pin 2 (+)
Pin 4 (+)
Pin 5 (+)
Pin 6 (-)
- 15 -
Power supply
24 V
GND
EN
8 9
rear view
