Fig. 5.6 shows the connection of analog sensors with output from 0 up to 10V DC
to the Analog Inputs.
VCC
VCC
Sensor1
Vo
GND
VCC
VCC
Sensor2
Vo
GND
AGND
Figure 5.6. Connecting analog sensors with output from 0 up to 10V DC to the
®
Analog Inputs
smartDEN IP-Maxi User Manual
09 Mar 2018
12V+
Fuse: 1.5A
-
- 23 -
