5.2. Power supply
smartDEN IP-Maxi must be powered with 12V DC stabilized and filtered voltage.
After power on, the power led must be on and STATUS indicator must start blinking
in 5 seconds which means the module is running normally (Fig. 5.2).
Please keep the polarity and the power supply voltage range!
smartDEN IP-Maxi does not accept AC power supply voltage. It is highly
recommended to check the power supply source parameters before the
module is powered on.
The power supply equipment shall be resistant to short circuit and overload
in secondary circuit.
When in use, do not place the equipment so that it is difficult to disconnect
the device from the power supply.
Figure 5.2. smartDEN IP-Maxi power supply
®
