3. Technical parameters

Parameter
Size (L / W / H), mm
Weight, g
Operating temperature, °C
Parameter
Power supply voltage, V DC
Maximum current consumption, mA
Protection against reverse polarity
Hardware Real Time Clock (RTC)
Default settings restore button
Reset button
Parameter
Digital inputs number
Digital inputs voltage range, V DC
Input switching threshold from 0 to 1, V DC
Input switching threshold from 0 to 1, mA
Input switching threshold from 1 to 0, V DC
Input switching threshold from 1 to 0, mA
Supported sensor output type
Input type
Protection against reverse polarity
Parameter
Counters number
Max. pulses frequency
®
Digital Inputs 1, 2, 3
Digital Inputs 4, 5, 6,
7
Digital Input 8
smartDEN IP-Maxi User Manual
Table 3.1. Physical parameters
Value
210 x 85 x 58
420
0 to 70
Table 3.2. System parameters
Value
12 or 24 (depends on the model)
±2
450 at 12V, 300 at 24V
Yes
Yes
Yes
Yes
Table 3.3. Digital inputs
Value
8
0 up to 30
> 7.6
> 3.2
< 4.5
< 1.8
PNP
Resistive with Schmitt trigger
Yes
Table 3.4. Counters
Value
8
1 ..10 Hz (
See point
9 kHz
40 kHz
09 Mar 2018
)
7.9
