Components Used To Create Configurations; Optional Components Required For A Complete Spray System; Safety Information; General Safety Information - Spraying Systems Co 1550+ AutoJet Owner's Manual

Hand held pendant trigger
o

Components Used to Create Configurations


Air regulator to control liquid pressure

Air regulator and solenoid valve for controlling atomizing air

Air regulator and solenoid valve for controlling fan air

Air Piloted Fluid Regulator – Not part of the Pressure Pot version

Optional Components Required for a Complete Spray System


Spray nozzles with spray tips or spray set ups

Spray nozzle mounting kits
 Spray nozzle hook-up kits

Safety Information

General Safety Information

Read and follow instructions
All safety related, and operating instructions should be read before the system is operated. Follow all operating
instructions.
Note: If the Model 1550+ AutoJet Modular Spray System is used in a manner other than as described in this Manual,
protection afforded by the equipment may be impaired.
Water and Moist ure
The control panels are rated NEMA 1, unless otherwise specified. The rating is only with the door closed and properly
locked. Being NEMA 1 rated, the control panels can withstand streams of water directed at them; however, we
recommend avoiding spraying on the unit externally if possible. The control panel is not washdown rated.
Servicing
For servicing of valves and pumps please refer to the appropriate manuals.
Do not attempt to service the 1550+ Modular Spray System Electrical Control Panel.

For service, contact your local Spraying Systems Co. sales representative by calling
1-800-95-SPRAY (1-800-957-7729)

For corporate support contact 1-866-321-2250.

Only authorized qualified service personnel should attempt to service the Control Panel.
Service by unauthorized personnel will void all warranties.
o
Replacement Parts
The 1550+ AutoJet Modular Spray System has been designed with components that work together to provide the best
system performance. When the system requires replacement parts, contact your local sales engineer, only Spraying
Systems Co. recommended components should be used to maintain proper system operation and safety.

Warnings

It is important to recognize proper safety precautions when using a pressurized spray system. Fluids under
W A RN I N G :
pressure can penetrate skin and cause severe injury.
W A RN I N G : When dealing with pressure applications, the system pressure should never exceed the lowest rated
component. Always know your system and all component capabilities, maximum pressures and flow rates.
