- Page 1 60 & 60W GunJet ® Spray Gun USER GUIDE MI-60 & 60W spray.com...
- Page 2 CONTENTS CONTENTS ......................2 INTRODUCTION ....................3 WARNINGS & PRECAUTIONS ................3 INSTALLATION ...................... 6 MAINTENANCE ..................... 7...
- Page 3 60W GunJet spray guns are identical and require the same installation and operating procedures. The Model 60 and 60W GunJet spray guns will accommodate standard Spraying Systems Co. accessories for both the inlet and the outlet connections within the accessories’ pressure and temperature limitations.
- Page 4 3. DO NOT alter equipment in any manner; if repairs are necessary, use only genuine factory repair parts supplied by Spraying Systems Co. 4. DO NOT exceed maximum operating pressure of the lowest rated accessory item within the spray system even though some of the accessories have a higher maximum pressure rating.
- Page 5 SAFETY SHOULD ALWAYS BE OBSERVED: 1. DO use a two-handed control of Model 60 GunJet at all times. Grasp spray gun firmly with both hands. If an extension is used, grasp the extension. (Insulated extension if spraying hot liquids.) 2. DO adopt a secure body stance prior to and during spray operation to safely control the high reactionary force of this unit.
- Page 6 INSTALLATION 1. Before installing GunJet® to hose, select WashJet ® tip or, if desired, an appropriate extension and WashJet nozzle for your application. Install on gun with nozzle positioned for your particular spraying needs and tighten. 2. Make sure all power is turned off to the pump. Attach GunJet to high-pressure hose with rating to meet or exceed the maximum operating pressure to be used.
- Page 7 With proper care, your Model 60 series GunJet® will give you reliable service. To maintain this performance, parts should be inspected regularly and replaced when necessary with genuine Spraying Systems Co. parts. DISASSEMBLY PROCEDURE: (See Figure 1 and parts list PL 60 & 60W, PL B60 & B60W or PL 60-3/8-SS) If it becomes necessary to disassemble this unit, follow these steps: 1.
- Page 8 Figure 1 Figure 1a ASSEMBLY PROCEDURE: (See Figure 1 and parts list PL 60 & 60W, PL B60 & B60W or PL 60-3/8-SS) 1. Install Main Spring (7) over Main Stem (6). 2. Install Washer (8) onto Main Stem (6). 3.
- Page 9 9. Thread flat side of hex Stem Nut (13) onto threaded end of Main Stem (6) until approximately 3/16” of threaded stem projects from recessed surface of Stem Nut (13). 10. Install #6 Burr (washer) (15), Spring (14), and end of Main Stem (6) which has hex Stem Nut (13) onto Trigger Guide (19).
- Page 10 DATA SHEETS...
- Page 16 North Avenue and Schmale Road, P.O. Box 7900, Wheaton, IL 60187-7901 Tel: 1.800.95.SPRAY Intl. Tel: 1.630.665.5000 Fax: 1.888.95.SPRAY Intl. Fax: 1.630.260.0842 www.spray.com MI-60 © Spraying Systems Co. 2019...
