Spraying Systems Co MeterJet User Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
23624-30L MeterJet
®
Spray Gun
USER GUIDE
MI-23624-30L
spray.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the MeterJet and is the answer not in the manual?

Questions and answers

Related Manuals for Spraying Systems Co MeterJet

Summary of Contents for Spraying Systems Co MeterJet

  • Page 1 23624-30L MeterJet ® Spray Gun USER GUIDE MI-23624-30L spray.com...

  • Page 2: Table Of Contents

    The adjustable metering sub-assembly allows the applicator to discharge precise volumes from 1 to 16 milliliters with a single pull of the MeterJet trigger. Release of the trigger automatically recharges the unit for the next dosage.

  • Page 3: Warnings & Precautions

    IMPORTANT: READ ALL INSTRUCTIONS BEFORE USING SPRAY GUN IT IS IMPORTANT TO RECOGNIZE THE PROPER SAFETY PRECAUTIONS WHEN USING A SPRAY GUN. WHILE THE METERJET® IS A RELATIVELY LOW-PRESSURE SPRAY GUN, DO NOT AIM, IT AT ANY PERSON OR PART OF THE BODY. FLUIDS UNDER PRESSURE CAN PENETRATE HUMAN SKIN AND CAUSE SEVERE INJURY.
  • Page 4 SAFETY SHOULD ALWAYS BE OBSERVED 1. DO use a “two-handed” control of 23624-30L MeterJet® at all times. Grasp spray gun firmly with both hands. If an extension is used, grasp the extension.

  • Page 5: Operation

    OPERATION ADJUST METERING CYLINDER The metering device of the MeterJet® Spray Gun consists of a cylinder (7), metering ring (14), and cylinder cap (15). A vertical scale from 1 to 16 milliliters (ml) in 2 ml increments is molded into the cylinder (7). A Vernier scale from 0 to 2 ml in 0.1 ml increments is located on the metering ring (14).

  • Page 6: Maintenance

    Therefore, the cylinder cap should be removed, and entire metering sub- assembly thoroughly flushed with clean water after each use. Failure to clean the MeterJet after each use may cause the piston to stick and render the device inoperable. MAINTENANCE With proper care, your 23624-30L MeterJet will give you reliable service.
  • Page 7 8. Remove spring sub-assembly (27 through 31). 9. While holding trigger assembly, loosen stem nut (20). Grip stem sub- assembly (5) with small pliers close to threads and gently remove from trigger guide (26). 10. Remove stem nut (20), trigger stop spring (21), and the #6 burr (22) from stem (5).
  • Page 8 5. Insert stem assembly (5) through inlet and metering bodies (6 & 16). 6. Install gasket (18) on packing screw (19). 7. If packing cup (17) was not previously removed from packing screw (19) apply a drop of light oil on packing cup and carefully thread packing screw over threads of stem sub-assembly (5).

  • Page 9: Petrofit Instructions For 30L Gunjet

    TRIGGER ADJUSTMENT PROCEDURE When correctly adjusted there should be no stem (5) travel when trigger lock (32) is engaged and trigger operation is attempted. A visual check can be made by detecting no stem nut (20) movement. Adjust main stem (5) to engage trigger guide (26) approximately 3/16"...
  • Page 10 INSTALLATION OF 23600-2 METERING SUB-ASSEMBLY (Refer to Parts List PL23624-30L) 1. Insert stem portion of metering sub-assembly (items 3 through 15) through inlet body (16) and tighten hex of body (6) to inlet body (16). When tightened, the metering sub-assembly (3 - 15) and inlet on inlet body (16) should be parallel.

  • Page 11: Parts List

    PARTS LIST...
  • Page 12 North Avenue and Schmale Road, P.O. Box 7900, Wheaton, IL 60187-7901 Tel: 1.800.95.SPRAY Intl. Tel: 1.630.665.5000 Fax: 1.888.95.SPRAY Intl. Fax: 1.630.260.0842 www.spray.com MI-23624-30L © Spraying Systems Co. 2019...

This manual is also suitable for:

23624-30l
