MTP51-JP User Manual
P
OWERING UP
Move the wireless power switch (see Fig. 1) in "I" position to activate wireless transmission: the
front LED
❷
lights up red and then green when the RF transmission power is on (blinking when
battery is low!)
S
ETUP CONTROL
Open transmitter Body to access the "display and controls" area (Fig. 3):
❶Graphics Display (OLED)
❷Channel selection buttons (ch)
❸MIC gain setup buttons (gain)
❹3 position selector (up / down / click)
Fig. 3
OLED Power UP (OLED IS IN OFF CONDITION)
Pushing down selector (click), oled turns on. A first menu with Serial Number and brand logo is
displayed, then <status> menu enters automatically.
Turn on the transmitter pushing and holding selector (click) > 2 sec, Serial Number menu is displayed
till (-/+) is selected.
OLED Power DOWN (OLED IS IN ON CONDITION)
Pushing and holding selector (click) > 2 sec, display is turned off.
Display turns off automatically after 15 sec, unless in <AUDIO> menu (with audio level < 5% from
nominal).
4
❷
❸
❹
CLICK
+
-
❶
