Product Introduction:

1. Designed for Hi-power multiple channels application, 12 channels output, and Max. 4A
current per channel, up to 1152W output power.
2. Easy operation with OLED screen and the touch buttons.
3. 3 kinds of mode optional: single color, color temperature, RGB.
4. Support 3 kinds of DMX ports with signal isolation function: 5-pin XLR, RJ45 and green
terminal (with signal amplifier function).
5. With RDM remote management protocol,
RDM master console, such as parameters browsing & setting, DMX address setting,
equipment recognization, etc.
6. With photoelectric isolation function.
7. With shortcut protection and over load protection, as well as warning function when
fault.
8. With fast self-testing function.
9. 16bit / 8bit resolution optional.
10. Multiple dimming curve (0.1~9.9) optional.
the operations can be completed via the
