2.2 Paper Installation
2.2.1 Paper Loading
POS891 adopts 79.5mm±0.5mm width thermal paper roll.
Steps of Loading Thermal Paper are as below:
Hold down the upper cover button on the left side, open the movable upper cover,
draw a certain length of the paper roll, put the paper end on the print head, close the
upper cover and press it downwards lightly.
1. Pay attention to the direction of loading paper, make the printing surface face to the
print head.
2. Please don't feed or draw the paper forwards or backwards with hands.
3. Keep clean of the print head, avoid to influence the printing quality.
2.2.2 Solution to Paper Jam
If cutter jam, turn off the power, and turn on again, the cutter will be back to original
position. If paper jam, open the paper strage cover, and take out the paper. If the
cutter can not be back to the original position, open the cover of it, and turn the white
plastic gear by the direction suggestive on the cutter by hand to make the cutter be
Figure 2-1 Printer Part Name Diagram
Caution!
！
5
Hide quick links:
Advertisement
Table of Contents
Need help?
Do you have a question about the SP-POS891 and is the answer not in the manual?
Questions and answers
how to provide page setup for sprt sp-pos891
The SPRT SP-POS891 printer allows parameter setup through the following steps:
1. Enter Setting Mode:
- Open the paper case cover.
- Press the FEED button twice.
- Close the paper cover.
- The printer will enter setting mode and print the first set of parameters with default values.
2. Adjust Parameters:
- Follow the instructions in Appendix A for detailed parameter settings.
3. Exit Setting Mode:
- Open the paper case cover.
- Press the FEED button.
- Close the paper cover and release the FEED button.
- The printer will save the settings and return to normal mode.
Note: The models SP-POS891USd and SP-POS891Udn do not support button-based parameter settings. Additionally, turning off the printer directly will not save changes.
This answer is automatically generated
