INVT Goodrive10 Series Operation Manual page 35

Goodrive10 VFDs
Function
Name
code
Asynchronous
P02.06 motor stator
resistor
Asynchronous
P02.07 motor rotor
resistor
Asynchronous
P02.08 motor leakage
inductance
Asynchronous
P02.09 motor mutual
inductance
Asynchronous
P02.10 motor non-load
current
Motor overload
P02.26
protection
Motor overload
P02.27
protection
Detailed description of parameters
0.001–65.535Ω
0.001–65.535Ω
0.1–6553.5mH
0.1–6553.5mH
0.1–6553.5A
0:No protection
1: Common motor (with low speed compensation).
Because the heat-releasing effect of the common motors
will be weakened, the corresponding electric heat
protection will be adjusted properly. The low speed
compensation characteristic
reducing the threshold of the overload protection of the
motor whose running frequency is below 30Hz.
2: Frequency conversion motor (without low speed
compensation) Because the heat-releasing effect of the
specific motors won't be impacted by the rotation speed, it
is not necessary to adjust the protection value during
low-speed running.
When P02.27=overload
motor/rated current of the motor
mentioned here
protection current
32
Function parameters
Default
value
Depend
on model
Depend
on model
Depend
on model
Depend
on model
Depend
on model
means
2
of the
100.0%
Modify
○
○
○
○
○
◎
○
