Goodrive10 VFDs
Function
Name
code
B frequency
P00.08 command
reference
Combination
P00.09 type of the
setting source
Keypad set
P00.10
frequency
Detailed description of parameters
be switched by the jumper.
Note: when AI2 selects 0–20mA input, 20mA corresponds
to 10V.
100.0% of the analog input corresponds to P00.03,
-100.0% of the analog input corresponds to the reverse
P00.03.
6: Multi-stage speed running setting
The VFD runs at multi-stage speed mode when P00.06=6
or P00.07=6. Set P05 to select the current running stage,
and set P10 to select the current running frequency.
The multi-stage speed has the priority when P00.06 or
P00.07 does not equal to 6, but the setting stage can only
be the 1–15 stage. The setting stage is 1–15 if P00.06 or
P00.07 equals to 6.
7: PID control setting
The running mode of the VFD is process PID control when
P00.06=7 or P00.07=7. It is necessary to set P09. The
running frequency of the VFD is the value after PID effect.
See P09 for the detailed information of the preset source,
preset value, feedback source of PID.
8:MODBUS communication setting
The frequency is set by MODBUS communication. See P14
for detailed information.
0: Maximum output frequency, 100% of B frequency setting
corresponds to the maximum output frequency
1: A frequency command, 100% of B frequency setting
corresponds to the maximum output frequency. Select this
setting if it needs to adjust on the base of A frequency
command
0: A, the current frequency setting is A freauency command
1: B, the current frequency setting is B frequency command
2: A+B, the current frequency setting is A frequency
command + B frequency command
3: A-B, the current frequency setting is A frequency
command - B frequency command
4: Max (A, B): The bigger one between A frequency
command and B frequency is the set frequency.
5: Min (A, B): The lower one between A frequency
command and B frequency is the set frequency.
Note:The combination
P05(terminal function)
When A and B frequency commands are selected as
"keypad setting", this parameter will be the initial value of
manner can be
24
Function parameters
Default
value
1
0
shifted by
50.00Hz
Modify
○
○
○
