AJAX Motion Protect User Manual page 11

The Ajax Motion Protect detector should be attached to a vertical surface or
in the corner.
1. Attach the Smart Bracket panel to the surface using bundled screws, using
at least two fixing points (one of them – above the tamper). After selecting
other attachment screws, make sure that they do not damage or deform the
panel.
The double-sided adhesive tape may only be used for temporary attachment of the detector. The
tape will run dry in the course of time, which may result in the falling of the detector and actuation
of the security system. Furthermore, hitting can damage the device.
2. Put the detector on the attachment panel. When the detector is fixed in
Smart Bracket, it will blink with an LED – this will be a signal that the
tamper on the detector is closed.
If the LED indicator of the detector is not actuated after installation in Smart
Bracket, check the status of the tamper in the
application and then the fixing tightness of the panel.
