Connectors and Jumpers
EATX12V1
Name
Pin
1 GND
2 GND
3 GND
4 GND
5 12 V
6 12 V
7 12 V
8 12 V
PWR3V1~ PWR3V3
Pin Name
1 3.3 V
2 3.3 V
3 3.3 V
4 GND
5 GND
6 GND
PWR5V1
Name
Pin
1 5 V
2 5 V
3 5 V
4 GND
5 GND
6 GND
VOLT1
Pin Name
1 5VSB
2 GND
3 GND
4 -5 V
5 5 V
6 3.3 V
7 -12 V
8 12 V
FAN1~ FAN7
Name
Pin
1 GND
2 12 V
3 FANIO1 ~ FANIO7
FANDEC1
Pin Name
1 FANIO1
2 FANIO2
3 FANIO3
4 FANIO4
5 FANIO5
6 FANIO6
7 FANIO7
SMBUS1~ SMBUS3
Pin Name
1 5 V
2 C-SMBCLK
3 C-SMBDAT
4 GND
JFP1
Name
Pin
1 PWRBTN#
2 GND
3 RESET#
4 GND
IPMB1
Pin Name
1 IPMB_CLK
2 IPMB_DAT
3 GND
