PCE-5B05V-30B1E Backplane: 5-slot BP for 2U Chas-
sis, 1 x PICMIG 1.3, 1x PCIe, 3 x 64-bit PCI-X
Startup Manual
Packing List
Before you begin installing your card, please make sure
that the following items have been shipped:
• One 2-port USB cable
• PCE-5B05V-30B1E startup manual
• M4*6*0.7 round screws (5 pcs)
• Warranty Card
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/Network/
For technical support and service, please visit our
support website at:
http://www.advantech.com/support
This manual is for the PCE-5B05V-30B1E series.
Part No. 200K5B0503
p/n: 1700002204
p/n: 1939000410
p/n: 2190000902
4th Edition
May 2016
Specifications
Standard Functions
• PICMIG 1.3 slots:
PCE-5B05V-30 supports PCE-5xxx CPU boards
• PCIe slots:
PCE-5B05V-30 supports one PCIe x16 slot
• 64-bit PCI-X:
Three 64 Bit / 100 MHz PCI-X slots
• USB (2.0) support:
Four Universal Serial Bus ports to backplane
Mechanical and Environment
• Dimensions: 80.01 x 325 mm
• Power supply voltage: +12 V, +5 V, -12 V, -5 V, +5 V
SBY, +3.3 V
• Power requirements: Refer to the CPU board, add-on
card and peripherals
• Operating temperature: 0 ~ 60° C
PCE-5B05V-30B1E Startup Manual 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PCE-5B05V-30B1E and is the answer not in the manual?

Questions and answers

Summary of Contents for Advantech PCE-5B05V-30B1E

  • Page 1 PCE-5B05V-30B1E Backplane: 5-slot BP for 2U Chas- sis, 1 x PICMIG 1.3, 1x PCIe, 3 x 64-bit PCI-X Startup Manual Packing List Specifications Standard Functions Before you begin installing your card, please make sure that the following items have been shipped: •...
  • Page 2: Connectors And Jumpers

    USB12 Two USB port pin header PCI 66MHz USB34 Two USB port pin header PCI 100MHz Jumpers PCI 133MHz Label Function PSON1 ATX / AT mode selection JP1VI01 P1PCIX1 and P1PCIX2 3.3V / 5V VIO Selection 2 PCE-5B05V-30B1E Startup Manual...
  • Page 3: Connector Pin Definitions

    3.3 V PSON -12 V 12 V FAN1 ~ FAN4 Name -5 V 12 V FANIO1 ~ FANIO4 FANDEC1 Name ATX12V1 FANIO1 Name FANIO2 FANIO3 FANIO4 12 V 12 V SMBUS1 ~ SMBUS2 Name C-SMBBUS C-SMBDAT PCE-5B05V-30B1E Startup Manual 3...
  • Page 4 Name USBV0 USBV0 JP1VIO1 USBD0- Name USBD1- USBD0+ USBD1+ PA_VIO PA_VIO Null PA_VIO 3.3 V USB34 3.3 V Name 3.3 V USBV2 JP1VIO1 3.3V 5V VIO 3.3V USBV2 USBD2- USBD3- USBD2+ VIO=5V VIO=3.3V USBD3+ (Default) Null 4 PCE-5B05V-30B1E Startup Manual...
  • Page 5 Locating Connectors & Jumpers P1PCIX3 P1PCIX1 P1PCIX2 PPCIE2 PPCIE1 FAN4 SMBUS1 SHBA1 JP1VIO1 SHBB1 SMBUS2 FANDEC1 PSON1 EATXPWR1 SHBC1 USB12 USB34 JFP1 VOLT1 IPMB1 FAN3 FAN2 SHBD1 ATX12V1 FAN1 EATX12V1 Figure 1: Locating Connectors PCE-5B05V-30B1E Startup Manual 5...
  • Page 6: Board Dimensions

    8.13 [0.320] 0.00 [0.000] 0.00 [0.000] 9.53 [0.375] 32.89 [1.295] 31.50 [1.240] 36.95 [1.455] 35.56 [1.400] 160.00 [6.299] 287.90 [11.335] 293.87 [11.570] 316.87 [12.475] Mechanical Drawing (solder side) Mechanical Drawing (component side) Figure 2: Mechanical Drawing 6 PCE-5B05V-30B1E Startup Manual...
  • Page 7: Board Diagram

    LAN X2 PCI Routing Tables PCI INTERRUPT PIN ROUTE PCI SLOT IDSEL INTA INTB INTC INTD P1PCIX1 PA _AD31 PA_INTD# PA_INTA# PA_INTB# PA_INTC# P1PCIX2 PA _AD30 PA_INTC# PA_INTD# PA_INTA# PA_INTB# P1PCIX3 PA _AD29 PA_INTB# PA_INTC# PA_INTD# PA_INTA# PCE-5B05V-30B1E Startup Manual 7...
