PCE-5B09-06 Backplane: 9-slot BP for 10-slot
Chassis, 1 PICMG 1.3, 2 PCIe, 6 32-bit PCI
Startup Manual
Packing List
Before you begin installing your card, please make sure that
the following items have been shipped:
1. PCE-5B09-06 Startup Manual
2. M4*6*0.7 Round Screws (20 pcs)
3. 2 Year Quality Warranty Card
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Specifications
Standard Functions
• PICMG 1.3 slots:
PCE-5B09-06 supports PCE-5xxx & PCE-7xxx CPU
boards
• PCIe slots:
PCE-5B09-06 supports one PCIe x 16 slot and one PCIe
x 4 slot
• 32-bit PCI:
Six 32 Bit / 33 MHz PCI slots
• USB (2.0) support:
Four USB 2.0 ports pin headers
Mechanical and Environment
• Dimensions: 222.35 mm x 327.61mm
• Power supply voltage: +12 V, +5 V, -12 V, -5 V, +3.3 V,
+5 V SBY
• Power requirements: Refer to the CPU Board, add-on
Card & Peripherals
• Operating temperature: 0 ~ 60° C
• Weight: 0.43 KG (weight of board)
The table below lists the function of each of the jumpers and
connectors:
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/ePlatform
For technical support and service, please visit our
support website at:
http://www.advantech.com/support
This manual is for the PCE-5B09-06 series Rev.A1
Part No. 20065B0910
Printed in China
p/n: 1939000410
p/n: 2190000902
1st Edition
March 2012
Connectors & Jumpers
Connectors
Label
Function
SHBA1 ~ SHBD1
PICMG1.3 CPU board slot
PPCIEX4_1
PCIe x 4 slot
PPCIEX16_2
PCIe x 16 slot
PPCI1 ~ PPCI3
32 Bit / 33 MHz PCI Bus slot
P1PCI1 ~ P1PCI3 32 Bit / 33 MHz PCI Bus slot
EATXPWR1
ATX 2.0 24-pin Power Connector
ATX12V1
ATX 12V 4-pin Power Connector
PWR3V1
Extension 3.3 V 6-pin Power
Connector for PCI slots
EATX12V1
Extension ATX 12 V 8-pin Power
Connector
VOLT1
Alarm board / CMM Power Connector
FAN1 ~ FAN7
FAN Connector
FANDEC1
FAN speed detector Connector
SMBUS1
SMBus Connector for chassis monitor
SMBUS2
SMBus Connector for chassis monitor
JFP1
Power and Reset button Connector
IPMB1
IPMB Connector
USB12
Two USB port pin header
USB34
Two USB port pin header
PCE-5B09-06 Startup Manual 1
