Advantech PCE-3B06-02 Startup Manual

PCE-3B06-02 Backplane: 6 Slot PICMG 1.3 Halfsize
BP for 6-slot Wallmount Chassis, 1 x PCIe x16,
2 x PCIe x1, 2 x 32-bit/33 MHz PCI
Startup Manual
Packing List
Before you begin installing your card, please make sure that
the following items have been shipped:
• PCE-3B06-02 startup manual
• 2-year quality warranty card
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://www.advantech.com.tw/support
This manual is for the PCE-3B06-02 series.
Part No. 20063B0600
Printed in China
p/n: 20063B0600
p/n: 2190000902
1st Edition
December 2013
Specifications
Standard Functions
• PICMG 1.3 slots:
- PCE-3B06-02 supports PICMG 1.3 half-size mainstream
SHB (PCE-3XXX series) and server grade SHB
(PCE-4XXX series)
• PCIe slots:
- PCE-3B06-02 supports one PCIe x16 slot, two PCIe x1
slot
• PCI slots:
- PCE-3B06-02 supports two PCI slots (32 bit/33 MHz)
Mechanical and Environment
• Dimensions: 176 x 142.17 mm
• Power supply voltage: +12 V, +5 V, -12 V, +3.3 V +5 VSB
• Power requirements: Refer to the CPU Board, add-on
card & peripherals
• Operating temperature: 0 ~ 60 °C
• Weight: 0.172 kg (weight of board)
