Connectors and Jumpers

IPMB1
IPMB connector
USB12
USB connector
USB34
USB connector
Power Connector for Advan-
tech Redundant Power Sup-
PSON2
ply: 1757001757, 1757001760,
1757001758, 1757001761,
1757001759, 1757001677
ISP1
PCIe re-driver F/W update port
Jumpers
Part Reference
Function
ATX/AT mode select connector
PSON1
1-2: AT mode
2-3: ATX mode (default)
PCIe generation selection connector
for primary switch
No jumper: Gen2
1-2: Gen3 (Default)
JGEN1
2-3: Gen1
* The PCIe generation setting is
backwards compatible. Suggest
choosing "Gen3" setting.
PCIe generation selection connector
for Secondary switch
No jumper: Gen2
1-2: Gen3 (Default)
JGEN2
2-3: Gen1
* The PCIe generation setting is
backwards compatible. Suggest
choosing "Gen3" setting.
Enable compatibility for Non-Com-
pliant Gen1 Endpoints
(Primary switch)
JCOMP1
1-2: Enable Gen1 Endpoints Com-
patibility (Default)
2-3: Normal
Enable compatibility for Non-Com-
pliant Gen1 Endpoints
(Secondary switch)
JCOMP2
1-2: Enable Gen1 Endpoints Com-
patibility (Default)
2-3: Normal
EATXPWR1
Name
Pin
1
3.3 V
2
3.3 V
3
GND
4
5 V
5
GND
6
5 V
2 PCE-7B17-00 Startup Manual
7
GND
8
PWROK
9
5VSBY
10
12 V
11
12 V
12
3.3 V
13
3.3 V
14
-12 V
15
GND
16
PSON#
17
GND
18
GND
19
GND
20
-5 V
21
5 V
22
5 V
23
5 V
24
GND
EATPWR1
Name
Pin
1
PWROK
2
5 V
3
12 V
4
-12 V
5
GND
6
GND
7
GND
8
GND
9
-5 V
10
5 V
11
5 V
12
5 V
ATX12V1 ~ ATX12V2
Pin
Name
1
GND
2
GND
3
12 V
4
12 V
