PCE-7B17-00A1E Backplane: 17-slot BP
for 20-slot chassis, 11 PCIe x4, and 5 PCIe x8
Startup Manual
Packing List
Before you begin installing your card, please make sure that
the following items have been shipped:
• PCE-7B17-00 start-up manual 2nd ED P/N: 20067B1701
• M4*6*0.7 Round Screws
• 2-year Quality Warranty Card
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Specifications
Standard Functions
• PICMG 1.3 slots: PCE-7B17-00 supports PCE-
5126WG2, PCE-7127
• PCIe slots: PCIe x4: 11; PCIe x8: 5 (Optional: PCIe x4:13;
PCIe x8:4, please create a T-part)
*If you have any questions about memory, I/O or IRQ
resource limitations, please contact Advantech locally or
FAE for further support.
• PCIe switch chip: PLX PEX8748
• USB (2.0) ports: 4 Universal Serial Bus ports as pin
headers
Mechanical and Environment
• Dimensions: 327.66 x 417 mm
• Power supply voltage: +12 V, +5 V, -12 V, -5 V, +3.3 V,
+5VSB
• Power requirements: Refer to CPU board, add-on card
& peripheral documentation
• Operating temperature: 0 ~ 60° C (Depending on sys-
tem thermal solution)
• Weight: 1.7 kg (weight of board)
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://www.advantech.com/support/
This manual is for PCE-7B17-00A1E.
Part No. 20067B1701
Printed in China
The backplane has a number of connectors and jumpers
that allow you to configure your system to suit your ap-
plication. The table below lists the function of each of the
connectors and jumpers.
P/N: 1939000410
P/N: 2190000902
Edition 2
August 2013
Connectors and Jumpers
Connectors
Part Reference
Function
SHBA1 ~ SHBD1
PICMG 1.3 CPU board slot
PPCIEX4_1
PCIe x4 with PCIe x16 slot
P1PCIEX4_3,
PCIe x4 with PCIe x4 slot
P1PCIEX4_4
(Primary switch)
P1PCIEX4_5,
PCIe x4 with PCIe x16 slot
P1PCIEX4_6
(Primary switch)
P1PCIEX8_1
PCIe x8 with PCIe x16 slot
P1PCIEX8_2,
(Primary switch)
P1PCIEX8_3
P2PCIEX4_1,
PCIe x4 with PCIex16 slot
P2PCIEX4_4 ~
(Secondary switch)
P2PCIEX4_6
P2PCIEX4_2,
PCIe x4 with PCIe x4 slot
P2PCIEX4_3
(Secondary switch)
P2PCIEX8_1,
PCIe x8 with PCIe x16 slot
P2PCIEX8_2
(Secondary switch)
EATXPWR1
ATX 2.0 24-pin power connector
EATPWR1
AT 12-pin Power connector
ATX 12 V Auxiliary 4-pin power
ATX12V1
connector1
ATX 12 V Auxiliary 4-pin power
ATX12V2
connector
EATX12V1
ATX 12 V 8-pin power connector
PWR3V1
3.3 V Auxiliary power connector
PWR3V2
3.3 V Auxiliary power connector
PWR3V3
3.3 V Auxiliary power connector
PWR5V1
5 V Auxiliary power connector
Alarm board / power
VOLT1
connector
FAN1 ~ FAN7
Fan connectors
FANDEC1
Fan detector connector
SMBUS1 ~
Chassis sensor board connectors
SMBUS2
JFP1
Power and reset button connector
PCE-7B17-00 Startup Manual 1
