BMS Configuration

Press the BMS Config button on the Configuration screen to display the BMS Config screen.

BACnet Settings

Press the BACnet* settings button on the BMS Config screen to display the BACnet Network screen. Press the right arrow to
display the BACnet Instance screen.
Imperial or Metric units
Baud rate settings
*BACnet is a registered trademark of ASHRAE
CONFIGURATION SCREENS
B M S C o nf i g
B A Cn et se t t i n gs
Z ig B ee C o nf i g
BACnet Network 1/ 2
CO M add ress
Network u ni ts
Baud rate
BACn et statu s
Due to our policy of continuous product innovation, some specifications may change without notification.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. "LG" is a registered trademark of LG Corp.
"254" value will set BACnet
254
network "Offline." To activate
"Online," choose a different
I mper i al
value
Auto
Indicates the controller
Offl i ne
status on the network.
41
