CONFIGURATION SCREENS

Basic Diagnostic

Press the Basic Diagnostic Button on the Configuration screen to display the Basic Diagnostic screen.
Firmware revision of the
controller
Pipe temperature
configuration
Press the right arrow on the Basic Diagnostic screen to display the next Basic Diagnostic screen.
Outlet pipe temperature
Outdoor Unit Silent Mode
Status
46
1/6 Basi c Diag no sti c
Firmw are rev.
ODU S t at u s
P i pe temp co nf.
2/ 6 Basic Di agn osti c
I nl et p ip e temp.
Ou tlet p ip e temp.
Mi dd le pi pe temp.
ODU sil ent mode
Sm art lo ad contr l
Mi dd le po i nt temp .
