Mantis Compact
OBJECTIVE SPECIFICATIONS
Objective Lenses
X2
X4
X6
Mantis Elite
Objective Lenses
X2
X4
X6
X8
X10
X15
X20
X6 SLWD
www.visioneng.com/support
Part Number
MCO-002
MCO-004
MCO-006
Part Number
MEO-002
MEO-004
MEO-006
MEO-008
MEO-010
MEO-015
MEO-020
MEO-006SL
OBJECTIVE SPECIFICATIONS
Working Distance
167mm / 6.57"
96mm / 3.78"
73mm / 2.87"
Working Distance
160mm / 6.29"
96mm / 3.78"
68mm / 2.68"
59mm / 2.32"
54mm / 2.13"
40mm / 1.57"
29mm / 1.14"
112mm / 4.41"
Field of View
45.0mm / 1.77"
27.5mm / 1.08"
19.2mm / 0.76"
Field of View
57.0mm / 2.24"
34.0mm / 1.34"
23.0mm / 0.91"
17.0mm / 0.67"
13.5mm / 0.53"
8.8mm / 0.35"
6.5mm / 0.25"
20.0mm / 0.79"
Mantis Service Manual
