MAINTENANCE & SPARE PARTS
Remove both of the screws that secure the lower head at the front.
Remove lower head.
Remove the 3 screws that secure the mirror assembly.
Remove/replace the mirror assembly.
Reverse the procedure to re-assemble.
17
www.visioneng.com/support
Mantis Service Manual
