1 1/2"
FLUSH
ofs.com
imagine a place®
Staks benching assembly
Worksurface installation
1.
Note: Support rails are used on 22", 30" and 36" deep tops that are wider than 48".
2.
Position support rail on bottom side of worksurface 6" from user edge in center
of worksurface.
3.
Attach with #10 x 5/8" screws.
Equal
Distance
4.
Place work surfaces on H-bases with side flush to edge of H-base.
5.
Leave 1 1/2" gap between back edge of work surface and tool bar.
6.
Secure work surfaces to H-bases with #12 x 1" screws.
800.521.5381
Assembly instructions
Straightener rails ship with tool rail kit
Model numbers:
SPTR66
SPTR60
SPTR54
SPTR48
Equal
Distance
6"
7
