  • Page 1 Obeya assembly instructions...
  • Page 2 Obeya assembly instructions Important safety instructions When using an electrical furnishing, basic precautions should always be followed, including the following: This furnishing is made for commercial use only. Read all instructions before using this furnishing: DANGER To reduce the risk of electrical shock: 1.

  • Page 3: Table Of Contents

    Obeya assembly instructions Instruction sheet reference Post & extrusion overview 2. Wall type post machining 6-10 3. Open & curtain wall overview 4. Framed panel wall overview - Full 5. Framed panel wall overview - Partial 6. Full panel wall overview 7.
  • Page 4 Obeya assembly instructions General assembly overview 1. Choose a starting wall from the layout dwg. 2. Locate both posts and extrusion for chosen starting wall. 3. Lay the extrusion on the floor with the hanging slots towards the top of the wall.

  • Page 5: Post & Extrusion Overview

    Obeya assembly instructions Post & extrusion overview 4 Way post T Post Corner post Mounting T slots in top & bottom of extrusions Single hanging rail for full & split Double wall panel hanging rails for cladding Mounting T screw bosses...

  • Page 6: Wall Type Post Machining

    Obeya assembly instructions Open and curtain wall post machining Beam mounting bracket machining ofs.com imagine a place® 800.521.5381 Assembly instructions...
  • Page 7 Obeya assembly instructions Framed panel wall post machining 1/4-20 Insert nut Beam mounting bracket machining Framed panel machining: 3 places Note: T post & 4 way post have 2 insert nuts for universal mounting ofs.com imagine a place® 800.521.5381 Assembly instructions...
  • Page 8 Obeya assembly instructions Full panel wall post machining 5/16-18 Insert nuts Top rail mounting bracket machining Cross rail machining: 2 places Wire management cutout ofs.com imagine a place® 800.521.5381 Assembly instructions...
  • Page 9 Obeya assembly instructions Split panel wall post machining Top rail mounting bracket machining Beam mounting bracket machining 5/16-18 Insert nuts Wire management cutout Cross rail machining ofs.com imagine a place® 800.521.5381 Assembly instructions...
  • Page 10 Obeya assembly instructions Table wall post machining Beam mounting bracket machining Worksurface beam mounting bracket machining: 30" dining or 42" bar height tops ofs.com imagine a place® 800.521.5381 Assembly instructions...

  • Page 11: Open & Curtain Wall Overview

    Obeya assembly instructions Open wall and curtain wall overview Beam Cladding Cladding Trim rail (curtain track included when option is chosen ) Post ofs.com imagine a place® 800.521.5381 Assembly instructions...

  • Page 12: Framed Panel Wall Overview - Full

    Obeya assembly instructions Framed panel wall overview - Full Beam Cladding Cladding Post Post Framed wall panel ofs.com imagine a place® 800.521.5381 Assembly instructions...

  • Page 13: Framed Panel Wall Overview - Partial

    Obeya assembly instructions Framed panel wall overview - Partial Beam Cladding Cladding Partial trim rail for open section Post Post Framed wall panel ofs.com imagine a place® 800.521.5381 Assembly instructions...

  • Page 14: Full Panel Wall Overview

    Obeya assembly instructions Full panel wall overview Top rail Cross rail Cross rail Post ofs.com imagine a place® 800.521.5381 Assembly instructions...

  • Page 15: Split Panel Wall Overview

    Obeya assembly instructions Split panel wall overview Beam Cladding Trim rail Cladding Top rail Cross rail Post ofs.com imagine a place® 800.521.5381 Assembly instructions...
  • Page 16 Obeya assembly instructions Table wall overview Beam cladding panel Beam Beam cladding panel Trim rail Worksurface Worksurface mounting bracket Worksurface beam Worksurface cladding panel beam post ofs.com imagine a place® 800.521.5381 Assembly instructions...

  • Page 17: Beam & Top Rail Attachment

    Obeya assembly instructions Beam and top rail attachment Top of post 5/16-18 x 1 3/4" Bolt Beam 1. Attach beam/ top rail to post mounting bracket using (2) 5/16-18 x 1 3/4" bolts for each post. 2. Slide bolts into rail from side access cutouts on each side of extrusion and into extruded screw boss.

  • Page 18: Cross Rail Attachment

    Obeya assembly instructions Cross rail attachment Post 5/16- 18 x 3/4" Bolt Cross rail 1. Insert 5/16-18 x 3/4" bolts into the pre installed insert nuts in the face of the post leaving them approx 3/8" out for cross rail mounting plate clearance.

  • Page 19: Trim Rail & Folding Curtain Attachment

    Obeya assembly instructions Open wall and curtain wall trim rails Warning: Machined slots are sharp! Access slot Beam 5/16-18 x 3/4" Bolt 5/ 1 6 Flat washer Trim rail 1. With all posts and extrusions assembled and leveled the trim rails can now be installed.
  • Page 20 Obeya assembly instructions Open wall and curtain wall trim rails - continued Warning: Machined slots are sharp. 5. Assemble folding curtain to the trim rail by sliding the curtain clips into the extrusion as shown. 6. Ensure to keep the alternating folds in the curtain while installing curtain onto trim rail.

  • Page 21: Cladding Installation

    Obeya assembly instructions Cladding panel Cladding panel w/ pre-installed hanging clips Cladding clip Beam Cladding panel Cladding clip 1. Lift cladding panel up to beam face with top of cladding approx. 1" above the top of the beam. 2. Apply light pressure to the face of the cladding panel and pull downward engaging the hanging clips into the hangings slots on the beam extrusion.

  • Page 22: Full Wall Panel Installation

    Obeya assembly instructions Full wall panel installation Wall panel Note: When doing a multi-panel wall, panels should be shifted so panels are tight against each other and approximately an 1/8" vein line between panel and post at each end. Tie down clip...

  • Page 23: Coat Hook Installation

    Obeya assembly instructions Coat hook Coat hook Full wall panel (back side) 1/4-20 Bolt Full wall panel w/ pre installed hanging clips 1. Attach coat hook before installing full wall panel on to structure. 2. Fasten coat hook to full wall panel using (2) 1/4-20 x 30mm bolts...

  • Page 24: Framed Wall Panel Installation

    Obeya assembly instructions Framed wall panel attachment Light sill attachment Wall assembly (posts & beam) Attach light sill flush to bottom of post in machined groove Light sill extrusion Bottom of post 1. With the wall structure assembled the framed wall panel can now be installed.
  • Page 25 Obeya assembly instructions Framed wall panel attachment Single panel full wall 1. Place the framed panel assembly into position between Beam access slot the posts ensuring the correct orientation so that the framed panel assembly is centered in the width of the post and the mounting holes in the frame align with the insert nuts in the edge of the post.
  • Page 26 Obeya assembly instructions Framed wall panel attachment Multi panel partial wall 1. Place the framed panel assembly that will attach to the post into position ensuring the correct orientation so that the framed panel assembly is centered in the width of the post and the mounting holes in the frame align with insert nuts in the edge of the post.
  • Page 27 Obeya assembly instructions Framed wall panel attachment - continued Multi panel partial wall 4. Place the next panel in place and repeat step 2 5. Slide the second panel tight against the first panel and secure using the panel to panel connection method noted below.
  • Page 28 Obeya assembly instructions Framed wall panel attachment Multi panel full wall 1. Place a framed panel assembly that will attach to a post into position ensuring the correct orientation so that the framed panel assembly is centered in the width of the post edge and the mounting holes in the frame align with the insert nuts in the edge of the post.
  • Page 29 Obeya assembly instructions Framed wall panel attachment - continued Multi panel full wall 3. Secure the framed panel assembly to the post using the 1/4-20 x 2.75" connector bolts. Insert one bolt into each of the holes in the framed panel vertical rail and thread into the insert nuts into the post edge leaving loose for panel adjustment.
  • Page 30 Obeya assembly instructions Framed wall panel attachment - continued Multi panel full wall 7. Tighten the fasteners for panel to panel connections so the vertical rails of both panels are fastened tight. 8. Shift the wall panel set so that there is an equal tolerance gap on each end between the outer framed panels and posts.

  • Page 31: Split Wall Panel Installation

    Obeya assembly instructions Split wall panel installation Split panel tie down clip Split wall panel Panel clip Hanging ledge Tie down slot Top rail Panel clip Hanging ledge Panel clip Cross rail 1. Once all posts and extrusions are installed for the structure and leveled and electrical is installed the split wall panels where applicable can be installed.
  • Page 32 Obeya assembly instructions Table wall worksurface assembly #8-32 x 3/4" FH screw Wall structure assembly: posts & beams Mounting plate Rectangle nut Cladding panel Note: Face cladding removed for clarity Worksurface Note: if not complete, assemble the worksurface mounting brackets by attaching two rectangle nuts to the bottom side of the mounting plate using (4) #8-32 x 3/4"...

  • Page 33: Roof Beam Attachment

    Obeya assembly instructions Roof beam attachment Mounting bracket 1. Attach mounting bracket to roof beam #8-32 x 3/4" extrusion with (2) 5/16-18 x 2.5" FH bolts from Machine screw the outside face and (2) 5/16-18 hex nuts from inside the extrusion.

  • Page 34: Ceiling Module Attachment

    #8 x 3/4" machine screw in each mounting bracket. Note: When filling the entire space with ceiling modules and using OFS strip lighting between ceiling modules leave a minimum 2 1/8" gap between modules.

  • Page 35: Runoff Tops - (Sitting/Bar) Assembly

    Obeya assembly instructions Obeya runoff worksurface assembly 1608904 #12 x 7/8" flat head wood screw 1609755 5/16-18 x 2" SHCS 1609077 1/4-20 x 5/8" FCHS Tools required Cordless drill 5/ 3 2" 3/ 1 6" 1/4" Allen wrenches Note: sitting height runoff worksurfaces will not use the foot ring and should bypass those steps in the assembly process.
  • Page 36 Obeya assembly instructions Obeya runoff worksurface assembly - continued Back of wall panel Worksurface bracket #8 x 3/4 " Wood screws Foot rail knuckle 1/4-20 x 1.5 SHCS 1/4-20 x 5/8 FH screw Note: the two mounting holes in the puck should be...
  • Page 37 Obeya assembly instructions Obeya runoff worksurface assembly - continued Back of wall panel Worksurface bracket #8 x 3/4 " Wood screws Foot rail knuckle 1/4-20 x 5/8 FH screw 1/4-20 x 1.5 SHCS Mount puck 5. Slide one end of each long foot rail onto each of the mount pucks on the panel.

  • Page 38: Full Wall Panel Worksurface Assembly

    Obeya assembly instructions Obeya wall panel worksurface assembly Back of wall panel Worksurface #8 x 3/4 " bracket Wood screws Note: Wedge tops require 2 mounting brackets along the back edge & 1 bracket along the wide end of the worksurface. Narrow end to face structure opening.

  • Page 39: Static Curtain Attachment

    Obeya assembly instructions Static curtain attachment Fixed rail Magnetic rail Static curtain 1. Unroll the static curtain to expose the mounting rail. 2. Remove the magnetic rail from the fixed rail by pulling opposite directions on both rails. 3. The curtain panel can be removed from the fixed rail if desired by pulling the top corner of the curtain separating the velcro mounting strip.

  • Page 40: Power Sleeve Installation

    Obeya assembly instructions Post power sleeve attachment Power sleeve 1. Install duplex receptacle into power sleeve receptacle housing. 2. Route and attach electrical jumper(s) before installing power sleeve. 3. Lift power sleeve approx 3/4" above post to align center of clips with mounting pins in post.

  • Page 41: Duplex Beam Attachment

    Obeya assembly instructions Duplex beam attachment Mounting plate #8 x 1/2" Screw Rectangle nut Duplex beam attachment Mounting bracket Extrusion 1. Assemble the mounting bracket by inserting a #8 x 1/2" machine screw into one of the holes in the mounting plate and threading on a rectangle nut from the back side.

  • Page 42: Seismic Anchor Bracket

    Obeya assembly instructions Seismic anchor bracket Required bracket configurations Corner post - 2 brackets T post - 3 brackets 4 Way post - 4 brackets Screws Post Anchor bracket 1. Attach anchor bracket to bottom of post in orientation shown below using supplied screws.

  • Page 43: Receptacle Full Wall Panel Attachment

    Obeya assembly instructions Duplex receptacle assembly - full wall panel Receptacle Duplex receptacle housing Back plate #8-32 x 1/2" Machine screw #8-32 x 1/2" Machine screw & flat washer Detail B Scale 1 : 2 1. Place receptacle housing into panel from front side.

  • Page 44: Receptacle Media Attachment

    Obeya assembly instructions Media duplex receptacle assembly Duplex receptacle 1. Attach mounting clip to outside face of Mounting clip L-bracket with the two threaded holes using (2) #8-32 x 1/2" pan head machine screws as shown. 2. Attach duplex receptacle to the mounting...
