ELEVEN WOOD
CORNER LEGS
INSTALLATION INSTRUCTIONS
NOTE: Views shown without the
worksurface for clarity purposes.
1.
Begin by removing the hex nuts and flat washers from the threaded studs
on each of the table legs. Attach the leg to the frame assembly by inserting
the threaded studs into the corresponding holes in the frame as shown in
the view above.
2.
Next, re-attach the flat washer and hand tighten the hex nut onto the
threaded stud. Repeat the previous steps for the remaining table legs. To
complete the assembly, fully tighten all the hex nuts using a 1/2" wrench.
FRAME
HEX NUT
PART # 1609141
THREADED STUD
FLAT WASHER
Advertisement
Related Manuals for Ofs ELEVEN WOOD
Summary of Contents for Ofs ELEVEN WOOD
- Page 1 ELEVEN WOOD PART # 1609141 CORNER LEGS INSTALLATION INSTRUCTIONS NOTE: Views shown without the worksurface for clarity purposes. Begin by removing the hex nuts and flat washers from the threaded studs on each of the table legs. Attach the leg to the frame assembly by inserting the threaded studs into the corresponding holes in the frame as shown in the view above.
- Page 2 ELEVEN WOOD PART # 1609142 66" ROUND AND SQUARE TABLES (66RT & 66SQT) INSTALLATION INSTRUCTIONS Begin by removing the hex nuts and flat washers from the threaded studs on each of the table legs. Attach the leg to the frame assembly by inserting the threaded studs into the corresponding holes in the frame as shown in the view in the upper right corner.
- Page 3 ELEVEN WOOD PART # 1609138 END LEG INSTALLATION INSTRUCTIONS NOTE: If your table has intermediate legs, they should be assembled prior to installing the end legs. Begin by locating the large diameter hole on top of the end legs. Next, drop the threaded cross dowel into the hole, making sure the slotted end is facing up.
- Page 4 ELEVEN WOOD PART # 1609139 END LEG WITH EXTENSIONS INSTALLATION INSTRUCTIONS NOTE: If your table has intermediate legs, they should be assembled prior to installing the end legs. Begin by dropping the threaded cross dowel into the hole on top of the extension, making sure the slotted end is facing up.
- Page 5 ELEVEN WOOD PART # 1609140 INTERMEDIATE LEGS INSTALLATION INSTRUCTIONS Begin by dropping the threaded cross dowel into the hole on top of the extension, making sure the slotted end is facing up. Then insert the threaded rod into the clearance hole on front of the extension and fasten it halfway into the cross dowel as shown in the view above.
- Page 6 ELEVEN WOOD PART # 1609112 FOOT RAIL ASSEMBLY INSTALLATION INSTRUCTIONS Begin by locating the (2) holes bored on the bottom of the cross rail on the leg. Insert a cross dowel into the hole, making sure the slotted end of the cross dowel is facing towards you.
-
Page 7: Installation Instructions
ELEVEN WOOD PART # 1609113 FOOT RAIL ASSEMBLY FOR TWO-PIECE TOP INSTALLATION INSTRUCTIONS Begin by locating the (2) holes bored on the bottom of the cross rail on the end legs. Insert a cross dowel into the hole, making sure the slotted end of the cross dowel is facing towards you. Next, insert the 4"... - Page 8 ELEVEN WOOD PART # 1609111 LIBRARY TACKBOARD INSTALLATION INSTALLATION INSTRUCTIONS Begin by locating the through holes on the bottom of the worksurface. Next, insert the mounting pin into the hole, making sure the longer portion of the pin is facing up. Lastly, utilizing the pre-drilled holes in the worksurface, fasten the mount pin to the top using the supplied screws from the HK-118 kit, as shown above.
