ofs.com
imagine a place®
Staks benching assembly
Power installation - economy kit
1.
Attach block clip to two T-nuts in toolbar using M6 x 10mm screws.
2.
See T-nut installation instructions on page 9.
Part #: 1554819
3.
Engage slotted grooves on top of double block system to flanges on block clips.
4.
Slide forward until each receptacle block snaps into place.
800.521.5381
T-nuts
Block clip
Assembly instructions
12
