Summary of Contents for Ofs LAUNCH LA-24358CT

  • Page 1 LAUNCH ASSEMBLY INSTRUCTIONS...
  • Page 2 Transformer Power Service (CT4) Transformer Power Service (CT4) Light Cover Lenses (CT4) Light Cover Lenses (CT4) Light Cover Lenses (CT4) HK-37 (#10-x 3/4” Quad Pan DT) HK-37 (#10-x 3/4” Quad Pan DT) HK-37 (#10-x 3/4” Quad Pan DT) Launch by OFS | 2...
  • Page 3: Installation Tips

    First Box. See page 12, Step 1. 5. Power/Data boxes must be secured with brackets or warranty will be voided. See page 12, Step 2. 6. Center powered tables requires additonal splitter. See page 14. Launch by OFS | 3...
  • Page 4 Drive lag bolts through the beams into the base and tighten securely. Level the base beam assembly at this time. Level should only be placed on mending plates while leveling since a “crown” is built into the beams. Launch by OFS | 4...
  • Page 5 If using Power/Data boxes, the table section with end opening labeled “A” must be over power source (Does not apply to Center Powered tables). Note: Illustrations display model LA-24358CT. Any variations in assembly for smaller models will be noted in the text. Launch by OFS | 5...
  • Page 6 Pull top sections together leaving no gap between top sections. Secure top sections together using four (4) 4" x 4" clamp plates (HK-6). Use eight (8) #8 x 3/4" flat head screws (HK-6) on each clamp plate. Launch by OFS | 6...
  • Page 7 Attach top to braces by using eight (8) #8 x 1" flat head screws (HK-68) on each brace. #8 x 1” Flat Head #8 x 1 1/2” Pan Head Note: Illustrations display model LA-24358CT. Any variations in assembly for smaller models will be noted in the text. Launch by OFS | 7...
  • Page 8 (HK-68) on each brace. Pre-Drill Here STEP 10 - L-BRACKET ATTACHMENT Space out 2 1/2" L-brackets evenly between bases and beam braces. Attach L-brackets by using four (4) #10 x 5/8" pan head screws (HK-10) on each L-bracket. Launch by OFS | 8...
  • Page 9 Attach clamp plates to top by using four (4) #8 x 5/8" pan head screws (HK-7) on each clamp plate. Note: Illustrations display model LA-24358CT. Any variations in assembly for smaller models will be noted in the text. Launch by OFS | 9...
  • Page 10 Handy Box enters this box first. On the CT4 models, the First Box contains the light switch. On the CT4 models, the wiring harness for the lights always plugs into the First Box. T-Connector CT4 Model Shown Launch by OFS | 10...
  • Page 11 -- For tables 108" to 189" -- One transformer and one harness are required for setup. -- For tables 216" to 243" -- Two transformers and two harnesses are required for setup, one on each side of the table top. Launch by OFS | 11...
  • Page 12 For Center Powered table, see page 14. Place Handy Box with plug-in cords inside of base. Plug male end of T-connector power cable into Handy Box. Plug female end of T-connector power cable into First Box. Launch by OFS | 12 Launch by OFS | 12...
  • Page 13 STEP 6 - CONNECT POWER/DATA BOXES Plug male end of T-connector power cable into First Box. Plug female end of T-connector power cable into adjacent box. Continue for all Power/Data Boxes. STEP 7 Plug Handy Box into floor outlet. Launch by OFS | 13...
  • Page 14 Management Column. Plug male end of T-connector power cable into Handy Box. Plug female end of T-connector power cable into Splitter. Plug in T-connector Power Cables from center of table out to ends of table. Launch by OFS | 14...
  • Page 16 OFS Brands company | 1204 East Sixth Street | Huntingburg, IN 47542 | 800-521-5381 | ofs.com 01.17 ™...
