Corner TV Wall Mount
Instruction Manual
SKU: MOUNT-CR02V
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/mount-cr02v
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Vivo MOUNT-CR02V
Summary of Contents for Vivo MOUNT-CR02V
- Page 1 Corner TV Wall Mount Instruction Manual SKU: MOUNT-CR02V Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/mount-cr02v GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com...
- Page 2 CAUTION! DO NOT INSTALL INTO DRYWALL ALONE. VERIFY YOUR WALL CONSTRUCTION. USE WOOD STUDS TO MOUNT. We include mounting for brick and concrete walls. If unsure, please contact us at vivo-us. com, email at help@vivo-us.com, or call us at 309-278-5303.
- Page 3 TOOLS NEEDED DO NOT EXCEED WEIGHT CAPACITY. 110lbs Failure to do so may result in serious injury. (49.90kg) Phillips Drill Screwdriver ASSEMBLY STEPS STEP 1 Insert sleeves (H) into arm (A). STEP 2 Place swivel bracket (F) over sleeves at end of arm as shown. Insert M8 carriage bolt (J) through bottom, secure with M8 nut (L), and tighten with the wrench (M).
- Page 4 STEP 3 OPTION A: Wood Stud Wall Installation Use arm (A) to mark mounting holes on wall where studs are located. Using a 1/4” drill bit, drill holes at least 2.4” deep into marked locations. Mount arm to wall using screws (W-A) with washers (W-C). OPTION B: Concrete/Brick Wall Installation Use arm (A) to mark mounting holes on wall.
- Page 5 STEP 4 Snap middle cover (B) and end covers (C) onto wall plate. STEP 5 OPTION A: Flat Back Monitor With TV face down on a flat surface, secure VESA brackets (E) to the TV using bolts (M-A, M-B) and washers (M-F, M-G).
- Page 6 STEP 5 (Continued) OPTION B: Curved Back Monitor With TV face down on a flat surface, secure VESA brackets (E) to the TV using bolts (M-C, M-D, M-E), spacers (M-H, M-I) and washers (M-F, M-G). Ensure safety bolts on brackets are positioned towards the bottom.
- Page 7 STEP 7 Loosen knob on arm to extend or reduce arm length. Tighten when finished adjusting. STEP 8 Hang TV with VESA brackets on TV plate, and tighten the safety bolts using a Phillips head screwdriver STEP 9 Secure cables to arm using the cable clip (G). Adjust TV position as desired.
