- Page 1 Electric TV Wall Mount MOUNT-E-M070R Series Assembly Manual Individual Product SKUs MOUNT-E-M070R MOUNT-E-M070R-W...
- Page 2 If you do not understand these directions, or if you have any doubts about the safety of the installation, please contact our product support team at 309-278-5303 or help@vivo-us.com for further assistance. Check carefully to make sure there are no missing or defective parts. Failure to report missing parts within 30 days may result in denial of free replacement.
-
Page 3: Package Contents
Package Contents A (x1) B (x2) C (x1) D (x1) Mount Wall Plate Cover Stencil TV Plate E (x2) F (x1) G (x1) H (x1) VESA Bracket Front Cover Remote Power Cord Included Hardware & Tools M-A (x4) M-B (x4) M-C (x4) M-D (x4) M6x14mm Screw... -
Page 4: Pre-Assembly
Preassembly Measure Wall Placement Use the chart below to determine the mounting height required above the mantle. b. Mount Height a. Mantel Extension b. This Mounting a. If Mantel Extends: Height is Required ≤ 4” (100mm) ≥ 3.1” (80mm) ≤ 7.8” (200mm) ≥... -
Page 5: Assembly Steps
Assembly Steps STEP 1 Option 1: Wood Stud Mounting Align the bottom edge of Stencil (C) with the Pre-Drilling Instructions measured height from the Preassembly Chart Drill mounting holes using and mark drilling locations using a pencil. Use illustration below. of a stud finder and level is recommended. -
Page 6: Option 2: Concrete Mounting
Option 2: Concrete Mounting Align the bottom edge of Stencil (C) with the Pre-Drilling Instructions measured height from the Preassembly Chart Drill mounting holes using and mark drilling locations using a pencil. Use of illustration below. a level is recommended. 3/8”... - Page 7 STEP 2 Plug Power Cord (H) into Mount (A). Snap Wall Plate Covers (B) onto Mount (A).
- Page 8 STEP 3 Plug Power Cord (H) into a power outlet. Short press the down button on Remote (G) and wait until the arm is fully lowered. **Warning** Keep hands clear of mount to prevent injury. Remove and discard the Plastic Wedge. Plastic Wedge...
- Page 9 STEP 4 Remove pre-installed Nuts (A1) and Metal Washers (A2) from Mount (A) using Wrench (T-A). Attach TV Plate (D) to Mount (A) using previously removed Nuts (A1) and Metal Washers (A2). Make sure TV Plate is level, and tighten nuts using Wrench (T-A).
- Page 10 STEP 4 - Cont’d Press Front Cover (F) onto TV Plate (D). STEP 5 Attach VESA Brackets (E) to the back of the TV using combination of Screws (M-A ~ M-D), M8 Washers (M-E), and Spacers (M-F, M-G) appropriate for your TV.
- Page 11 STEP 6 Remove the Nut (E1) from each VESA Bracket (E) and flip open the clip. Hang the TV with VESA Brackets (E) onto TV Plate (D). Close the clips and reinstall previously removed nuts using Wrench (T-A) to secure. 2 Person Mounting Recommended...
- Page 12 STEP 7 Manage cables using Cable Clips on the arm. Cable Clip The TV can be manually leveled left and right.
-
Page 13: Remote Control Manual
Remote Control Manual Upward Movement Stop Downward Movement Note: The bottom buttons have no functionality. Requires 2x AAA Batteries (not included) First Time Use 1. Install two AAA batteries (not included) in the Remote. 2. Plug the mount in. The mount will beep once, and will be ready for operation. Upward/Downward Movement Short press the button, the TV will move upward. -
Page 14: Remote Functions
• The weight of the TV may exceed the maximum weight limitation of the system. • The motor wire may be broken. Reset the Mount. If the problem persists, please contact us at 309-278-5303 or help@vivo-us.com for a replacement. Q. The Mount is making an abnormal noise. -
Page 15: Specifications
MOUNT-E-M070R Series Specifications Product Name Electric TV Wall Mount MOUNT-E-M070R Model MOUNT-E-M070R-W Input Power 100-240V~50/60Hz 2.5A Output Power 29.0V~1.8A 52.2W Receive Frequency Only 2437MHz Working Environment 0°C~40°C... - Page 16 Need Help? We’re Here For You Monday-Friday from 7am-7pm CST Saturday 8am-4pm CST Email Us Chat with Live Agent Give Us a Call help@vivo-us.com www.vivo-us.com 309-278-5303 ext. 1 FOR MORE GREAT VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: WWW.VIVO-US.COM VIVO-us @vivo_us @VIVOus VIVO...
