Cubicle monitor mount

Advertisement

Quick Links

Cubicle Monitor Mount
Instruction Manual
SKU: MOUNT-CUB1
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/mount-cub1
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303

Advertisement

loading
Need help?

Need help?

Do you have a question about the MOUNT-CUB1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Vivo MOUNT-CUB1

  • Page 1 Cubicle Monitor Mount Instruction Manual SKU: MOUNT-CUB1 Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/mount-cub1 GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com 309-278-5303...
  • Page 2: Package Contents

    WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
  • Page 3: Assembly Steps

    ASSEMBLY STEPS STEP 1 OPTION A For a cubicle wall with a thickness from 63mm to 89mm, make sure the L-Bracket on mount (A) has the short side facing out. min63mm-max89mm OPTION B For a cubicle wall with a thickness from 37mm to 63mm, make sure the L-Bracket on mount (A) has the long side facing out.
  • Page 4 STEP 2 Apply adhesive pads (B) to mount (A) as shown. STEP 3 Fit mount (A) to cubicle wall, and secure with the knob on top.
  • Page 5 STEP 4 Remove the screw from the top of the VESA plate, and slide the VESA plate off of mount (A). STEP 5 OPTION A: Flat Back Monitor For flat back monitor, install VESA plate to monitor using screws (M-A or M-C) and washers (M-E). M- E M- A M- C...
  • Page 6 STEP 5 (Continued) OPTION B: Curved Back Monitor For curved back monitor, install VESA plates to monitor using screws (M-B or M-D), washers (M-E), and spacers (M-F). M- E M- B M- D M- F STEP 6 Slide monitor onto mount (A) and secure with the previously removed screw.
  • Page 7 STEP 7 Rotate monitor to desired position. 360° STEP 8 To adjust monitor height, pull the lever behind the monitor, then raise or lower as desired.
  • Page 8 - 92% within < 3hr www.vivo-us.com : < 15 M AVG. RESOLUTION TIME (within office hrs) Chat live with an agent! : 5M 4S 309-278-5303 AVG. RESOLUTION TIME (within office hrs) FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
