TV Wall Mount 75x75mm to 200x200mm
Instruction Manual
SKU: MOUNT-VW01
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/mount-vw01
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
309-278-5303
Chat live with an agent!
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Vivo MOUNT-VW01
Summary of Contents for Vivo MOUNT-VW01
- Page 1 TV Wall Mount 75x75mm to 200x200mm Instruction Manual SKU: MOUNT-VW01 Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/mount-vw01 GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
-
Page 2: Package Contents
CAUTION! DO NOT INSTALL INTO DRYWALL ALONE. VERIFY YOUR WALL CONSTRUCTION. USE WOOD STUDS TO MOUNT. We include mounting for brick and concrete walls. If unsure, please contact us at vivo-us. com, email at help@vivo-us.com, or call us at 309-278-5303. -
Page 3: Assembly Steps
ASSEMBLY STEPS STEP 1 OPTION A: Wood Ceiling Use mount (A) to mark mounting holes on wall where stud is located. Using a 3/16” bit, drill approximately 2.2” into marked locations. Secure mount (A) to wall using bolts (W-A) and washers (W-C). - Page 4 STEP 2 Attach plastic cover to mount (A). STEP 3 Attach cable management clip (F) as shown in diagram.
- Page 5 STEP 4 Mount VESA adapters (C) and (D) to VESA plate (B) using bolts (J) and nuts (I) in the appropriate configuration to match your televisions mounting holes.
- Page 6 STEP 5 After placing TV on a flat surface, mount VESA plate (B) to back using bolts (M-A, M-B, or M-C) and washers (M-E or M-F). If bolts are too long, spacers (M-G) may be required.
- Page 7 STEP 6 Attach TV to mount (A) using nuts (E) as shown in diagram. STEP 7 Adjust mount (A) using allen wrench (G) and wrench (H). Adjust as Desired...
