Mount Designed for Dell OptiPlex Micro
Instruction Manual
SKU: MOUNT-DLMM1
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/mount-dlmm1
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303

Advertisement

loading
Need help?

Need help?

Do you have a question about the MOUNT-DLMM1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Vivo MOUNT-DLMM1

  • Page 1 Mount Designed for Dell OptiPlex Micro Instruction Manual SKU: MOUNT-DLMM1 Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/mount-dlmm1 GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
  • Page 2: Package Contents

    WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury.
  • Page 3 ASSEMBLY OPTION A: Desk Clamp STEP 1 For Desktops with a 10mm to 40mm Thickness: Dissemble Clamp (C) using a Phillips screwdriver. Turn Lower Clamp (C1) upside and reassemble Clamp (C) as shown below. *For Desktops with a 15mm to 50mm Thickness: Proceed to Step 2.
  • Page 4 STEP 3 Secure Locking Plate (B) to back side of Mounting Plate (A) using M5x6mm Screws (S-D), M5 Washer (S-G), and a Phillips screwdriver. STEP 4 Place assembly onto desktop and tighten hand bolt to secure.
  • Page 5 STEP 5 Attach Pads (E) to the PC to procect against accidental damage, then securely place the PC into the mount. Secure using Thumbscrews (S-A). Attach Cable Straps (D) to slots on underside of assembled mount to secure charging cord power brick.
  • Page 6 ASSEMBLY OPTION B: VESA Plate - Monitor Arm STEP 1 Secure Mounting Plate (A) to VESA holes on the back of the monitor using M4x10mm Screws (S-C) and M4 Washers (S-E) and a Phillips screwdriver. STEP 2 Attach Locking Plate (B) to the front side of the VESA Plate from your monitor mount using M4x10mm Screws (S-C), M4 Nuts (S-F) and a Phillips screwdriver.
  • Page 7 STEP 3 Secure Locking Plate (B) to Mounting Plate (A) using M5x6mm Screws (S-D), M5 Washers (S-G), and a Phillips screwdriver. STEP 4 Attach Pads (E) to the PC to procect against accidental damage, then securely place the PC into the mount.
  • Page 8 STEP 5 Attach Cable Straps (D) to slots on underside of assembled mount to secure charging cord power brick. Secure VESA plate to monitor mount using manufacturer guidelines.
  • Page 9 ASSEMBLY OPTION C: VESA Plate - Freestanding Monitor STEP 1 Secure Mounting Plate (A) to VESA holes on the back of the monitor using M4x10mm Screws (S-C) and M4 Washers (S-E) and a Phillips screwdriver. Secure Locking Plate (B) to Mounting Plate (A) using M5x6mm Screws (S-D), M5 Washers (S-G), and a Phillips screwdriver.
  • Page 10 STEP 2 Attach Pads (E) to the PC to procect against accidental damage, then securely place the PC into the mount. Secure using Thumbscrews (S-A).
  • Page 11 STEP 3 Attach Cable Straps (D) to slots on underside of assembled mount to secure charging cord power brick.
  • Page 12 : 1HR 8M (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
