White Pneumatic Arm Single Laptop Wall Mount
Instruction Manual
SKU: MOUNT-V001GLW
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/mount-v001gl
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Vivo MOUNT-V001GLW
Summary of Contents for Vivo MOUNT-V001GLW
- Page 1 White Pneumatic Arm Single Laptop Wall Mount Instruction Manual SKU: MOUNT-V001GLW Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/mount-v001gl GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
-
Page 2: Package Contents
DO NOT INSTALL INTO DRYWALL ALONE. VERIFY YOUR WALL CONSTRUCTION. USE WOOD STUDS TO MOUNT. We include mounting hardware for brick and concrete walls. If unsure, please contact us at vivo-us.com, email at help@ vivo-us.com, or call us at 309-278-5303. - Page 3 STEP 1 (Continued) OPTION B: Brick/Concrete Wall Use a pencil to mark drilling locations and drill 2.4” (60mm) deep holes using a 3/8” (10mm) bit. Mount arm (A) to wall using ST6.3x55 screws (W-A), concrete anchors (W-B) and D6 washers (W-C). STEP 2 Press covers (B) into screw holes.
- Page 4 STEP 2 While holding the arm straight forward, adjust arm tension by turning the screw on top of the center arm joint with the 5mm Allen wrench (C). Turn clockwise to reduce tension and counterclockwise to increase. The tension should be just enough to hold your monitor in place without lifting itself up.
- Page 5 STEP 5 Adjust monitor position as desired. OPTION B: LAPTOP INSTALLATION STEP 1 Place laptop arms (E) underneath each side of the laptop tray (D), aligning the square holes in the arms with the edge and long slot on each side. Insert clips (F) through the top to secure the arms, making sure all 4 locks on each clip are engaged with the square holes in the arms.
- Page 6 STEP 4 While holding the arm straight forward, adjust arm tension by turning the screw on top of the center arm joint with the 5mm Allen wrench (C). Turn clockwise to reduce tension and counterclockwise to increase. The tension should be just enough to hold your laptop in place without lifting itself up.
- Page 7 STEP 6 Insert cables and replace covers while making sure the cables have enough slack to allow enough free movement of the arm. STEP 7 Adjust laptop position as desired.
- Page 8 : 1HR 8M (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
