Car Tablet Mount
Instruction Manual
SKU: MOUNT-CAR02
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/mount-car02
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303

Advertisement

loading
Need help?

Need help?

Do you have a question about the MOUNT-CAR02 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Vivo MOUNT-CAR02

  • Page 1 Car Tablet Mount Instruction Manual SKU: MOUNT-CAR02 Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/mount-car02 GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com 309-278-5303...
  • Page 2: Package Contents

    WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury.
  • Page 3: Assembly Steps

    ASSEMBLY STEPS STEP 1 Begin by identifying what foot style is needed for your passenger seat configuration, using the images below. Please note that the two front seat bolts of some vehicles will differ from each other in angle. 90° 0°...
  • Page 4 STEP 1 - Continued Install compatible Foot (B, C, D) for your passenger seat’s left bolt to the threads on Connecting Bracket (L) using M6 Nuts (S-C), M6 Washers (S-B), and Wrench (T-B). Please note, based on your passenger seat’s floor bolts, you may need a different foot than what was used above.
  • Page 5 STEP 3 Loosen the front seat bolts on passenger seat using a socket wrench (size needed depends on manufacturer). Slide the left foot under the left seat bolt and the right foot under the right seat bolt. Adjust the placement as needed and re-tighten bolts.
  • Page 6 STEP 4 Attach Pole (F) to back of Base (A) using Knobs (I).
  • Page 7 STEP 5 Thread Support Screws (K) onto Base (A) and place Screw Caps (P) onto the ends once threaded.
  • Page 8 STEP 6 1. Slide Arm (G) onto Pole (F) with the adjustment bolt pointing up. Tighten and secure with 5mm Allen Wrench (T-A). Adjust the arm tension using 5mm Allen Wrench. 2. Determine desired Pole (F) height and Insert M6x45mm Screw (S-J) into slot. Secure using M6 Flanged Nut (S-I), making sure the flanged, wider part of the nut is faing outward, with the hex side fitting into the hex indention on Pole (F).
  • Page 9 STEP 7 Mount the Adapter (K) to the Arm (F) using the M4x16mm Thumbscrews (S-F) with M4 Washers (S-G) in mounting holes. Loosely install remaining M4x16mm Thumbscrews (S-F) into the top adjustment holes in Adapter. Place Cable Clips (H) on Arm (F) to manage cables.
  • Page 10 STEP 8 If assembled mount feels unlevel, tighten Support Screws (I) to level out. STEP 8 Note: Before continuing, we recommend checking that your tilt joint on your VESA mount is tight. To adjust the Adapter (K) to fit the device, push device down onto springloaded tabs and position device against the face of the adapter.
  • Page 11 STEP 9 To remove the device, while holding both sides of the device, pull down, tilt the devide, then lift it out. Reinstall the device in reverse order Device...
