TBS CLOUD
All the TBS Crossfire transmitters* and the Fusion video receiver includes a built-in WiFi module which
allows you a connection with all your gear through the TBS Cloud. This allows for features like VTx
follow**, dynamic VTx power** and other upcoming features.
Note: at the moment all the Cloud features require a hotspot with internet access.
*if you own a Standard Tx from 2015/2016, the WiFI module in the JR adapter is missing. You can replace
the adapter with a new one ​
**​ T BS Fusion v​ i deo receiver required
Menu
● WiFi Client
AP Mode: ​ e nables/ disabled the WiFI module
○
○ Default SSID:​ enables/ disables the SSID broadcast
SSID:​ SSID/ name of the connected/ selected network
○
○ Password:​ enter the password for the network
Connect:​ manually connect to the network. Only necessary when a new network is chosen
○
under ​ S SID
Scan: ​ scans for WiFI networks. Found networks can be chosen under ​ S SID​ , manual
○
reconnect by ​ C onnect ​ i s required
○ Forget WiFi:​ erases all saved networks and there password
Upgrade:​ starts the self update for the WiFI firmware.​ Disabled at the moment
○
● UDP
MAVLink:​ enables/ disables the sending of MAVlink data over the wifi
○
○ Port: ​ c hange the UDP port where the telemetry will be send
WebUI
●
○ Login:​ enables/ disables the login with or without a password
○ Password:​ set up a password for the WebUI login
About
●
○ WiFi: ​ n ame of the network your Crossfire is connected to
IP:​ IP address the module got
○
○ Server:​ connection status
Firmware: ​ v ersion number of the WiFI firmware
○
○ Hardware: ​ h ardware revision of the WiFI module
Bootloader:​ version number of the Bootloader firmware
○
f rom TBS​ .
