Receiver functions
Output map
On all receivers you can select what it should output on which pin. The available options for each differ for
the receivers:
Receiver pin Output type Diversity RX (standard)
1
2
3
4
5
6
7
8
Receiver pin
1
2
3
4
5
6
7
8
PWM Ch1 bis 12, PPM, RSSI, LQ, RSSI/LQ
PWM Ch1 bis 12, PPM, RSSI, LQ, RSSI/LQ
PWM Ch1 to 12, RSSI, LQ, RSSI/LQ, SBUS, n.i.SBUS, Serial
TX, MAVLink TX, CRSF TX, SmartAudio
PWM Ch1 bis 12, RSSI, LQ, RSSI/LQ, Serial RX, MAVLink RX,
CRSF RX
PWM Ch1 bis 12, RSSI, LQ, RSSI/LQ
PWM Ch1 bis 12, RSSI, LQ, RSSI/LQ, Serial RTS
PWM Ch1 bis 12, RSSI, LQ, RSSI/LQ, Serial RX, MAVLink RX,
CRSF RX
PWM Ch1 to 12, RSSI, LQ, RSSI/LQ, SBUS, n.i.SBUS, Serial
TX, MAVLink TX, CRSF TX, DSMX, SmartAudio
Output type Diversity RX (Nano)
PWM Ch1 bis 12, PPM, RSSI, LQ, RSSI/LQ, CRSF TX
PWM Ch1 bis 12, PPM, RSSI, LQ, RSSI/LQ, CRSF RX
PWM Ch1 to 12, RSSI, LQ, RSSI/LQ, SBUS, n.i.SBUS, Serial
TX, MAVLink TX, CRSF TX, DSMX, SmartAudio
PWM Ch1 bis 12, RSSI, LQ, RSSI/LQ, Serial RX, MAVLink
RX, CRSF RX
PWM Ch1 bis 12, RSSI, LQ, RSSI/LQ, Serial RTS
PWM Ch1 bis 12, RSSI, LQ, RSSI/LQ, Serial RTS
PWM Ch1 bis 12, RSSI, LQ, RSSI/LQ, Serial RX, MAVLink
RX, CRSF RX
PWM Ch1 to 12, RSSI, LQ, RSSI/LQ, SBUS, n.i.SBUS, Serial
TX, MAVLink TX, CRSF TX, DSMX, SmartAudio
40
Default value
PWM Ch. 1
PWM Ch. 2
PWM Ch. 3
PWM Ch. 4
PWM Ch. 5
PWM Ch. 6
PWM Ch. 7
PWM Ch. 8
Default value
PWM Ch. 1
PWM Ch. 2
PWM Ch. 3
PWM Ch. 4
PWM Ch. 5
PWM Ch. 6
PWM Ch. 7
PWM Ch. 8
