Danfoss VLT AutomationDrive FC 303 Instruction Manual page 96

Specifications
UL Compliance
Fuses or circuit breakers are mandatory to comply with NEC 2009. We recommend using a selection of the following.
The fuses below are suitable for use on a circuit capable of delivering 100,000 Arms (symmetrical), 240V, or 480V, or 500V,
or 600V depending on the Adjustable frequency drive voltage rating. With the proper fusing, the drive Short Circuit Current
Rating (SCCR) is 100,000 Arms.
FC 300
Bussmann
Power
[kW]
Type RK1 1)
0.25–0.37 KTN-R-05
0.55–1.1 KTN-R-10
1.5 KTN-R-15
2.2 KTN-R-20
3.0 KTN-R-25
3.7 KTN-R-30
5.5 KTN-R-50
7.5 KTN-R-60
11 KTN-R-80
15–18.5 KTN-R-125
30 [22] KTN-R-150
40 [30] KTN-R-200
37 KTN-R-250
Table 10.5 200–240V, Frame Sizes A, B, and C
FC 300
SIBA
Power
[kW] Type RK1
0.25–0.37 5017906-005
0.55–1.1 5017906-010
1.5 5017906-016
2.2 5017906-020
3.0 5017906-025
3.7 5012406-032
5.5 5014006-050
7.5 5014006-063
11 5014006-080
15–18.5 2028220-125
22 2028220-150
30 2028220-200
37 2028220-250
Table 10.6 200–240V, Frame Sizes A, B, and C
VLT ® AutomationDrive Instruction
Manual
Recommended max. fuse
Bussmann Bussmann
Type J Type T
JKS-05 JJN-05
JKS-10 JJN-10
JKS-15 JJN-15
JKS-20 JJN-20
JKS-25 JJN-25
JKS-30 JJN-30
KS-50 JJN-50
JKS-60 JJN-60
JKS-80 JJN-80
JKS-125 JJN-125
JKS-150 JJN-150
JKS-200 JJN-200
JKS-250 JJN-250
Recommended max. fuse
Littel fuse
Type RK1
KLN-R-05
KLN-R-10
KLN-R-15
KLN-R-20
KLN-R-25
KLN-R-30
KLN-R-50
KLN-R-60
KLN-R-80
KLN-R-125
KLN-R-150
KLN-R-200
KLN-R-250
®
MG.33.AI.22 - VLT is a registered Danfoss trademark
Bussmann Bussmann
Type CC Type CC
FNQ-R-5 KTK-R-5
FNQ-R-10 KTK-R-10
FNQ-R-15 KTK-R-15
FNQ-R-20 KTK-R-20
FNQ-R-25 KTK-R-25
FNQ-R-30 KTK-R-30
- -
- -
- -
- -
- -
- -
- -
Ferraz-
Shawmut
Type CC
ATM-R-05
ATM-R-10
ATM-R-15
ATM-R-20
ATM-R-25
ATM-R-30
-
-
-
-
-
-
-
Bussmann
Type CC
LP-CC-5
LP-CC-10
LP-CC-15
LP-CC-20
LP-CC-25
LP-CC-30
-
-
-
-
-
-
-
Ferraz-
10
Shawmut
Type RK1 3)
A2K-05-R
A2K-10-R
A2K-15-R
A2K-20-R
A2K-25-R
A2K-30-R
A2K-50-R
A2K-60-R
A2K-80-R
A2K-125-R
A2K-150-R
A2K-200-R
A2K-250-R
