Danfoss VLT AutomationDrive FC 303 Instruction Manual page 17

Installation
2 2
1
9
Figure 2.5 Typical Electrical Connection
1 PLC
2 Adjustable frequency drive
3 Output contactor (Generally not recommended)
4 Grounding rail (PE)
5 Cable insulation (stripped)
2-4
VLT
Manual
2
10
L1
L2
L3
PE
MG.33.AI.22 - VLT
® AutomationDrive Instruction
8
6 Min. 7.9 in [200 mm] between control cables, motor and line
power
7 Motor, 3-phase and PE
8 Line power, 3-phase and reinforced PE
9 Control wiring
10
Equalizing min. 0.025 in
®
is a registered Danfoss trademark
3
4
6
7
2 2
[16mm ]
5
U
V
W
PE
