INSTRUCTION MANUAL
(M169B01-03-18A)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Wibeee Max and is the answer not in the manual?

Questions and answers

Related Manuals for Circutor Wibeee Max

Summary of Contents for Circutor Wibeee Max

  • Page 1 Consumption analysers INSTRUCTION MANUAL (M169B01-03-18A)
  • Page 2 Wibeee Max Instruction Manual...

  • Page 3: Safety Precautions

    DISCLAIMER CIRCUTOR, SA reserves the right to make modifi cations to the device or the unit specifi ca- tions set out in this instruction manual without prior notice. CIRCUTOR, SA on its web site, supplies its customers with the latest versions of the device specifi cations and the most updated manuals. www.circutor.com CIRCUTOR, recommends using the original cables and accessories that are supplied with the device.

  • Page 4: Table Of Contents

    3�1�- PRELIMINARY RECOMMENDATIONS ����������������������������������������������������������������������������������������������������7 3�2�- INSTALLATION �����������������������������������������������������������������������������������������������������������������������������������������8 3�3�- SENSORS FOR CURRENT MEASUREMENT ���������������������������������������������������������������������������������������10 3�3�1�- Wibeee Max ���������������������������������������������������������������������������������������������������������������������������������������10 3�3�2�- Wibeee Max Plus ������������������������������������������������������������������������������������������������������������������������������ 11 3�4�- DEVICE TERMINALS ������������������������������������������������������������������������������������������������������������������������������13 3�5�- CONNECTION DIAGRAMS ��������������������������������������������������������������������������������������������������������������������13 3�6�- STARTING UP THE DEVICE �������������������������������������������������������������������������������������������������������������������14 3�6�1�- APPLICATION MODE �����������������������������������������������������������������������������������������������������������������������14 3�6�2�- DIRECT SHARE MODE ��������������������������������������������������������������������������������������������������������������������15...

  • Page 5: Revision Log

    Wibeee Max REVISION LOG Table 1: Revision log� Date Revision Description 12/17 M169B01-03-17A Initial Version Changes in the following sections: 06/18 M169B01-03-18A 1.- 3.2. - 3.3.1. SYMBOLS Table 2: Symbols� Symbol Description Compliant with the relevant European standards. Double insulation.

  • Page 6: 1�- Verifications Upon Reception

    - Wibeee Max Plus model: FLEX Wibeee 54 flexible sensors. 2�- DESCRIPTION OF THE PRODUCT The Wibeee Max is a device that measures three-phase lines and is connected to the cloud via the Wibeee platform. The device has been designed to make the installation process as simple as possible.

  • Page 7: 3�- Installing The Device

    The Wibeee Max device must be installed by authorised and qualified staff. Disconnect the device from the power supply and disconnect the measuring devices before handling, changing the connections or replacing the device. Handling the device while it is con- nected is hazardous to people nearby.

  • Page 8: 3�2�- Installation

    Wibeee Max 3.2.- INSTALLATION Before using the Wibeee Max ensure that the conditions are appropri- ate for working, and that the protective equipment is adequate� The flexible current sensor has been designed and tested to ensure that it complies with the IEC 61010-1:2001/EN61010-1 61010-2-31:2002 safety standard.
  • Page 9 3� Connect the device. See “3.4.- DEVICE TERMINALS” “3.5.- CONNECTION DIAGRAMS” 4� Once the Wibeee Max has been connected to the auxiliary power supply, check that the red LED is on and flashing (see “4.3.- LED INDICATORS” 5� Select the measurement scale for the current sensors: The Wibeee Max model, following the steps indicated in section “3�3�1�1�- Scale se-...

  • Page 10: 3�3�- Sensors For Current Measurement

    Deviation 50 Hz - 60 Hz 0.3 % Note : Circutor also has the model of flexible sensors, FLEX Wibeee 14, with the same metro- logical characteristics of the FLEX Wibeee 25 model, but with a length of 14 cm.

  • Page 11: 3�3�2�- Wibeee Max Plus

    When the scale selection period has ended, the quick blinking light is deactivated and the blue LED indicates the selected scale at regular intervals. 3�3�2�- Wibeee Max Plus In the Wibeee Max Plus model, current measurement is performed using the FLEX Wibeee 54 flexible sensors. Table 6:Metrological characteristics�...
  • Page 12 The FLEX Wibeee 54 current sensors indicate the selected scale through the blue and red LEDs on their head. During the first 20 seconds after being switched on, the Wibeee Max Plus is in the scale selec- tion period. The blue and red LEDs flash slowly and indicate the selected scale. Press the RESET key during this period to select the desired scale: ...

  • Page 13: 3�4�- Device Terminals

    Wibeee Max 3.4.- DEVICE TERMINALS Table 9:List of terminals of the Wibeee Max� Terminals of the Wibeee Max device 1: Current measurement: Black: L1 , Red: L2, Yellow: L3 2: Voltage measurement and power supply: Black: L1 , Red: L2, Yellow: L3, Blue: Neutral Green and Brown: Power supply.

  • Page 14: 3�6�- Starting Up The Device

     Application mode.  Direct share mode. 3�6�1�- APPLICATION MODE In application mode, the data measured by the Wibeee Max is uploaded to the cloud and ac- cessed using the Wibeee CIRCUTOR application. When using this mode, the Wibeee Max and the user who has configured it are linked, so the user can control the device, view the data that has been sent and the charts and manage groups of devices.

  • Page 15: 3�6�2�- Direct Share Mode

    Wibeee Max 3�6�2�- DIRECT SHARE MODE In direct share mode the Wibeee Max's data is directly accessed from the device's integrated web server, so you can view the measurements being captured at that moment in real time and manually configure the device. This allows you to change parameters, such as the server and port to which the Wibeee Max will send the data. If you configure a Wibeee Max while using...

  • Page 16: 4�- Operation

    Note: The device's integrated web server can also be accessed in the application's operating mode. If the Wibeee Max loses the connection with the server, a back-up memory with a 30-day capacity will start up. This back-up memory will store the values of the most critical variables (voltage, current, apparent power, active power, reactive power and power factor) every minute for 30 days.

  • Page 17: 4�2�- Measurement Parameters

    Wibeee Max 4.2.- MEASUREMENT PARAMETERS The device measures, logs and displays the following parameters, Table 10 Table 10: Measurement parameters of the Wibeee Max Display Parameter Units Phases Three-phase L1 - L2 - L3 Numerical Current Graphical Graphical Numerical Voltage...

  • Page 18: 4�4�- Key

    Restore the device's factory settings. To do this, hold down the RESET button for 10 seconds, until the device's red and blue LEDs simultaneously flash three times. 4.5.-START-UP During the start-up of the device, the Wibeee Max goes through different states: 1�- Configuration state Blue LED → Slow blinking light (1s) Red LED → Slow blinking light (1s)
  • Page 19 Blue LED → Off Red LED → Slow blinking light (1s) In this state, the Wibeee Max is managing the connection with the router/access point. This state should last for 40 seconds, when there is good Wi-Fi coverage. In places where there is weak Wi-Fi coverage, it may take longer.

  • Page 20: 5�- Display And Configuration

    Figure 8: Data display based on the operating mode� 5.1.-MOBILE APPLICATION The Wibeee Circutor mobile application is compatible with iOS and Android, and has a version for smartphones and tablets. In it you can view and configure all of the parameters measured by the device. Figure 9: Wibeee Circutor mobile application� Instruction Manual...

  • Page 21: 5�2�- Web Platform

    Wibeee Max 5.2.- WEB PLATFORM shows the main screen of the http://wibeee�circutor�com web platform. Figure 10 Figure 10:Main screen of the web platform� From this screen you can access the different sections of the platform: : Home, summary of consumption, displays charts and gives access to the ...

  • Page 22: 5�2�1�- Home

    Wibeee Max 5�2�1�- HOME The Home screen is divided into different areas:  The area in displays a summary of consumption and CO emissions from the Figure 11 previous month, the current month and the forecast for the end of the month. It also displays the set target value.
  • Page 23 Wibeee Max Figure 12: Charts area�  The area in shows the latest measurements sent by the device. Figure 13 Figure 13: Measurements area�  In the area in you can access the configuration options for the devices and Figure 14 dashboard, see 5.2.1.1.- Configuration screen for the devices/dashboard...
  • Page 24 Wibeee Max 5.2.1.1.- Configuration screen for the devices/dashboard. On the device/dashboard configuration screen you can configure the following data:  DEVICE Figure 15: Configuration screen: Device. The device’s basic data is entered in this section: Name: The name of the device. Select Dashboard: Dashboard selection. Mac: MAC address of the device.
  • Page 25 Wibeee Max The device’s location data is entered in this section: Name: Name of the device’s location. Time zone: Time zone. Longitude, Latitude: Location of the device.  COST Figure 17: Configuration screen: Cost The costs are entered in this section: Price kWh : Price of kWh.

  • Page 26: 5�2�2�- Dashboard

    Wibeee Max In this section you enter the following: Target Limit (kWh) : The maximum consumption value that you want to reach, in kWh. And the following notifications are activated or deactivated: • Wibeee has been inactive for 1 day. • Wibeee has been inactive for 3 days.

  • Page 27: 5�2�3�- Devices

    Wibeee Max 5�2�3�- DEVICES The Devices screen, , displays a list of all of the connected devices. Figure 21 Figure 21: Devices screen� 5�2�4�- NOTIFICATIONS The Notifications screen, , shows a log of all of the notifications that have been Figure 22 generated. Figure 22: Notifications screen. Instruction Manual...

  • Page 28: 5�2�5�- Reports

    Wibeee Max 5�2�5�- REPORTS The Reports screen, , is divided into two areas: Figure 23 Figure 23: Reports Screen�  REPORTS This section shows the scheduled reports to be regularly generated. To create a new regular report, press the icon. The dialogue box in opens.
  • Page 29 Wibeee Max In this dialogue box, you should enter: Report name: Name with which the report is going to be saved. Select Dashboard: Select the Dashboard on which you are going to prepare the report. Frequency: Select the frequency of the report: Weekly, Monthly, Billing period.

  • Page 30: 5�2�6�- Help

    Wibeee Max 5�2�6�- HELP The Help screen, , tries to answer any questions about the installation, operation, web Figure 26 platform and application of the Wibeee systems. Figure 26: Help Screen� 5.3.- INTERNAL WEB SERVER shows the screen where you access the device's internal web server. The device's Figure 27 default address is: http://192�168�1�150...

  • Page 31: 5�3�1�- Instant Data

    Wibeee Max � The main screen is shown in Figure 28 Figure 28:Main screen of the internal web server� 5�3�1�- INSTANT DATA In this section you can access instant data from each of the measurement phases, Figure 29 Figure 29:Internal web server: Instant Data�...

  • Page 32: 5�3�2�- Network

    Wibeee Max 5�3�2�- NETWORK You can configure the network parameters in the Network section, Figure 30 Figure 30:Internal web server: Network� 5�3�3�- ADVANCED OPTIONS You can configure the IP parameters in the Advanced Options section, Figure 31 wibeee.circutor.com Figure 31:Internal web server: Advanced Options� Instruction Manual...

  • Page 33: 5�3�4�- General Options

    Wibeee Max 5�3�4�- GENERAL OPTIONS shows the General Options section. Figure 32 Figure 32:Internal web server: General Options� You can configure the following parameters in this section: Connection Type: Connection type Measures Refresh Time (s): The measurement refresh time. Data Refresh Time (min): The data refresh time. If the value is set to -1, the sending of data is deactivated.

  • Page 34: 5�4�- Configuration Through Http Get Requests

    Requests must be made directly to the IP address: 192.168.1.150 after connecting to the Wi-Fi network created by the device. All requests made to the Wibeee Max's internal server are GET requests and when they have been processed by the server it sends an HTTP correct access response: “HTTP 200 OK”.
  • Page 35 Wibeee Max Figure 34:HPPT queries: Values of the device's variables� Table 12: Variables table� Variable Description Units <var>measuresRefresh</var> Measures refresh time of the internal web Seconds <var>appRefresh</var> Time sending data to the server. Minutes <var>softVersion</var> Firmware version of the device <var>model</var>...

  • Page 36: 5�4�2�- Configuration

    Capacitive Reactive Energy L2 VArCh <var>ereactc3</var> Capacitive Reactive Energy L3 VArCh <var>ereactct</var> Total Capacitive Reactive Energy VArCh 5�4�2�- CONFIGURATION The minimum requests for configuring the Wibeee Max with HPPT are: 1�- Device Network Configuration: http://ip_address/config_value?name=WIBEEE&dhcp=false&ip=c0a80196&gw=- c0a80101&subnet=ffff0000&id=0.5973659041337669 Table 13: Configuration HPPT variables (Request 1) Variable Description name Name of the Wibeee...
  • Page 37 Wibeee Max Table 12 (Cont�): ConFiguretion HPPT variables (Request 1) Parameter Symbol Gateway in hexadecimal subnet Subnet mask in hexadecimal 2�- Configuration of the Local Wi-Fi Network: h t t p : / / i p _ a d d r e s s / c o n f i g _ v a l u e ? s s i d = C i r p r o t e c - A l m a c e n & s e c u r i t y = 5 & t y - pekey=2&id=0.5105853546410799...

  • Page 38: 6�- Wireless Communications

    Function 0x05. Writing of a specific register. This function is used to delete the Wibeee Max's energy meters. If the Wibeee max receives a function request other than those above, or for non-specified memory registers, the device identifies this as an “Illegal error” and responds with the appro- priate exception code.

  • Page 39: 6�4�- Modbus Memory Map

    Wibeee Max As it is a MODBUS TCP server, the device number internally assigned to the Wibeee Max is 1. By default, once configured, the Wibeee Max starts to send data over the internet to the CIR- CUTOR server. If you want to stop this data from being sent (for example, because the local network does not have an Internet connection) you have to set a data refresh time of -1.
  • Page 40 Wibeee Max Table 17 (Cont�): Modbus memory map� Parameter Symbol Address Units Capacitive Reactive Energy L1 EreactC1 002A - 002B kVarh Capacitive Reactive Energy L2 EreactC2 002C - 002D kVarh Capacitive Reactive Energy L3 EreactC3 002E - 002F kVarh Total Capacitive Reactive Energy...

  • Page 41: 7�- Technical Features

    Wibeee Max 7�- TECHNICAL FEATURES Power supply 100 ... 400 V ~ Rated Voltage Frequency 50 ... 60 Hz Consumption 4.5 ... 9 VA Voltage measurement circuit Voltage measurement margin 100 ... 440 V Ph-N Frequency measurement margin 50 ... 60 Hz Min�...
  • Page 42 Self-extinguishing VO Plastic (UNE 21031 90ºC) 4,50 4,50 49,41 105,28 54,41 Figure 35: Wibeee Max dimensions� Standard Safety requirements for electrical equipment for measurement, control, IEC 61010-1: 2001 and laboratory use -- Part 1: General requirements Safety requirements for electrical equipment for measurement, control...

  • Page 43: 8�- Maintenance And Technical Service

    • CIRCUTOR accepts no liability due to the possible damage to the unit or other parts of the installation, nor will it cover any possible sanctions derived from a pos- sible failure, improper installation or “improper usage”...

  • Page 44: 10�- Ce Certificate

    Wibeee Max 10�- CE CERTIFICATE Instruction Manual...
  • Page 45 Wibeee Max Instruction Manual...
  • Page 46 Wibeee Max Instruction Manual...
  • Page 47 Wibeee Max Instruction Manual...
  • Page 48 CIRCUTOR, SA Vial Sant Jordi, s/n 08232 - Viladecavalls (Barcelona) Tel.: (+34) 93 745 29 00 - Fax: (+34) 93 745 29 14 www.circutor.com central@circutor.com...
