3.2.- INSTALLATION
To install the device, carry out the following steps:
1� Remove the protective panel from the electric panel.
8
Before using the Wibeee Max ensure that the conditions are appropri-
ate for working, and that the protective equipment is adequate�
The flexible current sensor has been designed and tested to ensure that
it complies with the IEC 61010-1:2001/EN61010-1 61010-2-31:2002 safety
standard.
Use of the sensor on uninsulated conductors is limited to 600 V ~ or DC to
frequencies below 1kHz.
Do not expose the device to aggressive or explosive environments.
Do not use the device if you have any reason to believe that it is not working
correctly or it is defective.
For measuring of uninsulated conductors, use the appropriate and necessary
personal protective equipment.
The device should be installed after the circuit breaker.
Figure 1: Remove the connection panel�
