Input/Output Ports

Holtek microcontrollers offer considerable flexibility on their I/O ports. Most pins can have either an
input or output designation under user program control. Additionally, as there are pull-high resistors
and wake-up software configurations, the user is provided with an I/O structure to meet the needs of
a wide range of application possibilities.
The device provides bidirectional input/output lines labeled with port names PA and PB. These I/O
ports are mapped to the RAM Data Memory with specific addresses as shown in the Special Purpose
Data Memory table. All of these I/O ports can be used for input and output operations. For input
operation, these ports are non-latching, which means the inputs must be ready at the T2 rising edge
of instruction "MOV A, [m]", where m denotes the port address. For output operation, all the data is
latched and remains unchanged until the output latch is rewritten.
Register
Name
7
PA PA7
PAC PAC7
PAPU —
PAWU PAWU7
PB —
PBC —
PBPU —
Pull-high Resistors
Many product applications require pull-high resistors for their switch inputs usually requiring the
use of an external resistor. To eliminate the need for these external resistors, all I/O pins, when
configured as an input have the capability of being connected to an internal pull-high resistor. These
pull-high resistors are selected using a registers PAPU and PBPU located in the Data Memory. The
pull-high resistors are implemented using weak PMOS transistors. Note that pin PA7 does not have
a pull-high resistor selection.
PAPU Register
Bit 7
Name —
R/W —
POR —
Bit 7 Unimplemented, read as "0"
PAPU6~PAPU0: Port A bit 6~bit 0 pull-high control
Bit 6~0
0: Disable
1: Enable
