COMMANDER SERIES REMOTE CONTROL ENTRY SYSTEM
INTRODUCTION
Thank you for purchasing the CMD-10k Commander from Dakota Digital. This, along
with many other products that Dakota Digital has to offer, represents the latest in electronics
technology for the street rod, classic car, sport truck, or custom vehicle.
The CMD-10k comes complete with receiver/controller, two key chain transmitters, one
sealed emergency release switch, and three dual relay packs. The unit can be installed and
configured to remotely release the driver's and passenger's door latches, provide up and down
control of both the driver and passenger side window, as well as release the trunk latch or operate
a trunk lift up and down. In addition to this, a pair of auxiliary outputs are provided for external
relays. These auxiliary relays can be set up as momentarily on or as latch-on, latch-off. A "flash"
output is available that is activated every time one of the latch outputs are activated. This can be
used to disable an aftermarket alarm system or connected to a relay to flash the parking lights.
The system incorporates a self-resetting circuit protection device on the latch release
outputs to protect against short circuits. A safety feature partially disables the system when the
ignition is on to avoid the accidental opening of a door during vehicle operation. With the ignition
on, the only functions that are allowed to work are the control of the power windows. An
emergency release switch can be concealed on the underside of the vehicle to roll the driver's
window down should the door ever be closed with the transmitter on the inside and you on the
outside.
ADDITIONAL TRANSMITTERS
The transmitters supplied with your remote system have a unique serial number coded into
each one for security. Each unit can "learn" up to 7 transmitters. Lost or stolen transmitters are
easily erased by simply reprogramming the remaining transmitters into the system again.
Transmitters from other manufacturers, such as car alarm systems, will not work with the CMD-
10k.
RADIO FREQUENCY INTERFERENCE STATEMENT
This device complies with part 15 of FCC rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) This device must
accept any interference received, including interference that may cause undesired operation.
CMD-10k
FCC IDENTIFIER: KNF6TX
1
Advertisement
Related Manuals for Dakota Digital COMMANDER Series
Summary of Contents for Dakota Digital COMMANDER Series
- Page 1 INTRODUCTION Thank you for purchasing the CMD-10k Commander from Dakota Digital. This, along with many other products that Dakota Digital has to offer, represents the latest in electronics technology for the street rod, classic car, sport truck, or custom vehicle.
-
Page 2: Installation
INSTALLATION The receiver should be mounted on the interior of the vehicle so that it is not exposed to moisture. It can be secured using the four mounting holes or with a double sided adhesive tape, such as Velcro. The main harness plugs into one end of the unit with a 16 pin connector and the antenna plugs into the other end with a 3 pin connector. - Page 3 For solenoids which require more than 10 amps, such as Dakota Digital’s PDR-2, an external relay should be used for powering the solenoid. FUSED CONSTANT...
- Page 4 Power window regulators are not included with the remote system base kit. They are available separately from Dakota Digital. This remote system is designed to wire into existing power windows or installed at the same time as power windows are added to the vehicle. Use the diagram which matches the way your power windows are connected.
- Page 5 POWER WINDOW WIRING Driver's Window Emergency Entry Switch BROWN REGULATOR AND SWITCH Special regulator or NOT INCLUDED an additional relay module required for this style SEALED GROUND SWITCH of wiring connection GROUND CONSTANT-ON FUSED +12V BLACK CHASSIS GROUND YELLOW TO CONSTANT-ON FUSED +12V PURPLE PURPLE...
- Page 6 POWER TRUNK LIFT WIRING The trunk lift motor is not included in the base package. These are available from Dakota Digital separately. REGULATOR AND SWITCH NOT INCLUDED WIRE COLORS COMING FROM TRUNK LIFT MAY VARY DEPENDING ON MANUFACTURER. CONSTANT-ON FUSED +12V...
-
Page 7: Power Door Lock Wiring
POWER DOOR LOCK WIRING The trunk raise/lower channels can also be used for power door locks to add more security to the vehicle. The door lock actuators are not included with the base package. These are sold separately if they are needed for your application. FACTORY DOOR LOCK SYSTEM CONSTANT-ON... - Page 8 Buttons III, IV, V, and VI will operate door latch releases. For solenoids which require more than 10 amps, such as Dakota Digital’s PDR-2, an external relay should be used for powering the solenoids on outputs III, IV and V. (see figure 3.) DIP switches #1 and #2 should both be off.
- Page 9 Drv. wind up/down Pass. wind up/down Drv. door latch Pass. door latch Trunk up/down Trunk latch Aux. 1/Aux. 2 OPERATION FOR MODE 1, DIP switch #1 OFF The key chain transmitter has six buttons. They are labeled with roman numerals I, II, III, IV, V, and VI.
- Page 10 Drv. wind up/down Pass. wind up/down (Trunk up) (Trunk down) Drv. door latch Pass. door latch (Aux 1 output) (Aux 2 output) Trunk latch Activate alternate function shown in ( ) OPERATION FOR MODE 2, DIP switch #1 ON The key chain transmitter has six buttons. They are labeled with roman numerals I, II, III, IV, V, and VI.
- Page 11 REMOTE SYSTEM TRANSMITTER LOCK FUNCTION Due to the long range of this system, some customers may wish to avoid accidentally pressing a button and opening a door when they are out of sight of the vehicle. Turning Switch #3 on will enable a transmitter lock function.
-
Page 12: Troubleshooting Guide
CMD-10k COMMANDER SERIES REMOTE ENTRY SYSTEM LIMITED LIFETIME WARRANTY DAKOTA DIGITAL (the Company) warrants to the ORIGINAL PURCHASER of this remote control product that should any included control relays, electronic module, or transmitters under normal use and condition, be proven defective in material or workmanship DURING THE LIFETIME OF THE CAR IN WHICH IT WAS ORIGINALLY INSTALLED, such defect(s) will be repaired or replaced (at the Company’s option) without charge for parts or labor directly related to repairs of the defect(s). - Page 13 This warranty gives you specific legal rights and you may also have other rights which vary from state to state. 4510 W. 61ST St. N., Sioux Falls, SD 57107 Phone: (605) 332-6513 FAX: (605) 339-4106 www.dakotadigital.com dakotasupport@dakotadigital.com ©Copyright 2005 Dakota Digital Inc.
