- Page 1 WALL UNIT 1000 Tall 2 Door Assembly Guide 1000 Tall For Internal Use: FI.WR.INS.047_WKIN00132_WALL_1000_2Dr_Tall_Rev3.indd...
- Page 2 WALL UNIT BEFORE YOU START 1000 Tall 2 Door INSTALLATION Assembly Guide SHOULD BE PERFORMED BY A COMPETENT PERSON ONLY. THIS PRODUCT COULD BE DANGEROUS IF INCORRECTLY INSTALLED Panel A Panel B Panel C Muntin D Loose Shelf Frontal x1 Back Panel...
- Page 3 WALL UNIT 1000 Tall 2 Door Assembly Guide Step 1. Seat dowel (F) into holes in Seat (G) end panel (B) as shown. cam dowel into hole as shown. Step 2. Seat cam dowel (G) into holes in end panel (B) as shown.
- Page 4 WALL UNIT 1000 Tall 2 Door Step 6. Seat dowel (F) Assembly Guide into holes in Seat (G) both panels (B) cam dowel as shown. into hole as shown. Step 7. Seat cam dowel (G) into holes in both end panels (B) as shown.
- Page 5 WALL UNIT Step 10. Ensure carcass is square. 1000 Tall 2 Door Assembly Guide Step Step 11. Join Slide the back panel clips (T) pane into the groove of both panels (B) & (A). screw The back panel clips (T) should be evenly...
- Page 6 WALL UNIT 1000 Tall 2 Door Assembly Guide Step 14. Hanging Brackets steps a,b & c to be carried out on both sides as shown Detail A Detail A Detail A Step a Step b Step c Insert Hanging Rotate locking...
- Page 7 WALL UNIT Step 17. 1000 Tall 2 Door Measure appropriately and attach the 2 x hanging bracket plates onto the wall screwing through the provided holes into your wall. Assembly Guide Screws for fixing to walls are not provided as these vary depending on your wall material and construction.
- Page 8 WALL UNIT Step 20. 1000 Tall 2 Door Insert hinge in top & bottom Assembly Guide holes as shown. Step 21. Secure hinges by tightening 2 x screws with hinge dowels attached. These are already positioned within the hinges. Step 22.
