IS-420
QUICK START GUIDE
Getting to know your mailing system
Screen main areas
D1
0000
1st Letter
0 g
No services
D2
20/01/20
Mem: None
D3
Acct: 11
D4
D1 Rate and services (to change: K1)
D2 Date printed (to change: K4)
D3 Weighing type (to change: K6)
D4 Imprint position offset
D5
Postage and weight
D6 Job memory (can contain rate, stamp settings
and account)
D7 Current account
Shortcut keys
K1
K7
K2
K5
K3
K8
K6
K4
K9
K1 Rates and services selection
K2 Memorized jobs (rate, stamp settings, account)
K3
Credit management
K4 Type of imprint and Imprint settings
K5 Label printing
K6 Weighing modes
K7 Sleep / wake (amber / green)
K8 Stops printing
K9 Starts printing
Applying postage
1
To reset the mailing system
Press :
To clear the information on the screen.
To wake the machine up with default
settings.
To return to the home screen
D5
D6
D7
2c
If you know the amount...
Key the postage in directly
1
Type the amount on the keyboard.
2
Press OK.
0000
The home screen
displays the postage.
Changing the ink cartridge
1
On the new ink cartridge,
remove the protective
strips from the printing
heads.
2
Raise base cover and
follow instructions printed
on sticker inside.
2a
To weigh your mail...
Put your mail on the scale
1
Check that the D3 icon is
2
Otherwise, press
option Standard weighing.
or
2b
Enter the weight manually
1
Press and then select the option
Manual weight entry.
2
Enter the weight and press OK.
4
When the postage is displayed...
Print the stamp
If you want to print on a label, see the alternative
sequence below.
0 g
1
Press to start the motors of your mailing
system.
2
Insert the mail piece in
the mail path, the
imprint printing position
on the upper right side.
To print on labels
1
Insert labels into the
dispenser until a click,
printing side facing the
right.
2
Press to enter the number of labels
to print and then press
If jamming occurs...
1
Press on the control
panel to stop the motor.
2
Under the base, lift up
the release handle and,
using your other hand,
remove stuck envelope
or labels.
For more specific information about your
mailing system, see the User Guide :
kbhelp.quadient.com/is420_ug_en_dl
.
and then select the
3
When the weight is displayed...
Choose rate and services
Current rate and selected
services are displayed in
this zone of the screen.
To change the rate and/or add services:
1
Press
The rate selection
screen is displayed.
2
Use the keypad to select an available Class
and/or Services, or select key 8 for the wizard.
3
Press OK to validate your selection and return
to the home screen.
.
Adding credit
, type 2 and follow the instructions onscreen.
Press
Note: to complete this operation successfully, your postal
services account must have a positive credit balance of the
corresponding amount.
0000
1st Letter
0 g
No services
20/01/20
1st Letter
0000
.
No services 0 g
Courier
1 Standard 2
Registered Priority
3 4
Express Wizard
5 6
