Terms

3.2

Safety instructions

Thoroughly read and abide by this user manual before commissioning the door. In addition, always observe the
following safety precautions:
The prescribed mounting, maintenance and repair work must be performed by properly trained personnel
à
authorised by GEZE.
The country-specific laws and regulations are to be observed during safety-related tests.
à
GEZE shall not be liable for injuries or damage resulting from unauthorised modification of the system.
à
GEZE shall not be liable if products from other manufacturers are used with GEZE equipment.
à
Only original GEZE parts may be used for repair and maintenance work.
à
The connection to the power supply must be made by a professional electrician. Perform the power connec-
à
tion in accordance with DIN VDE 0100-610.
à The electrical installation at the customer has to have an all-pole power disconnector that can be secured reli-
ably against reactivating (e.g. lockable switch with at least 3 mm contact opening).
A customer-side 10 A overload cut-out must be used as the line-side disconnecting device.
à
Observe the latest versions of guidelines, standards and country-specific regulations, in particular:
à
BGR 232 "Guidelines for power-operated windows, doors and gates"
à
DIN 18650, Part 1 and 2 "Automatic door systems"
à
DIN VDE 100-600 "Installation of low-voltage systems - Part 6 Tests"
à
DIN EN 60335-1 "Safety of electrical devices for home use and similar purposes"
à
Accident-prevention regulations, especially BGV A1 (VBG1) "General regulations", and BGV A3 (VBG4)
à
"Electrical systems and equipment"
4 Terms
Term
Drive sides at 1-leaf
systems
Drive sides at 2-leaf
systems
Contactors
Contactor with switch
function
Push & Go
Stop
4
Statement
The side of the track on which the drive unit is located, is usually the closing direction of the
sliding leaf
The side of the track on which the drive unit is located, is usually the opening direction of the
sliding leaf
Button, switch or motion detector for actuating the sliding door drive.
Actuation function in the "Automatic" operating mode
Button for opening and closing the sliding leaf. Actuation function only in the "Automatic"
operating mode. The sliding leaf is opened automatically when the button is first pressed and
closed again automatically when the button is pressed the second time. The function can be
activated during commissioning by parameter configuration.
If the sliding leaf is pressed manually out of the closing position during an activated Push & Go
function in the "Automatic" operating mode, the sliding leaf opens automatically.
Self-locking switch with which immediate stopping of the sliding door drive can be triggered
in case of danger. The sliding door drive remains in its current position until the user releases
the stop switch again, thus terminating the stop situation.
